RC1040/1080/1090
 2005 Radiocrafts AS RC1040/RC1080/RC1090 Data Sheet (rev. 1.3) Page 9 of 17
RF Frequency, Output Power Levels and Data Rates
The following table shows the available RF channels and their corresponding frequencies,
and nominal output power levels.
Model RF channel Output power Data rate
RC1040 1: 433.302 MHz
2: 433.711 MHz
3: 433.916 MHz
4: 434.092 MHz
5: 434.319 MHz
1: -14 dBm
2: -6 dBm
3: 0 dBm
4: 6 dBm
5: 9 dBm
1: 1.2 kbit/s
2: 2.4 kbit/s
3: 4.8 kbit/s
4: 9.6 kbit/s
5: 19.2 kbit/s
RC1080 1: 868.130 MHz
2: 868.297 MHz
3: 868.366 MHz
4: 868.800 MHz
5: 868.919 MHz
6: 869.021 MHz
7: 869.526 MHz
8: 868.840 MHz
1: -15 dBm
2: -10 dBm
3: -5 dBm
4: 0 dBm
5: 5 dBm
1: 1.2 kbit/s
2: 2.4 kbit/s
3: 4.8 kbit/s
4: 9.6 kbit/s
5: 19.2 kbit/s
RC1090 1: 903.0 MHz
2: 906.0 MHz
3: 909.0 MHz
4: 912.0 MHz
5: 915.0 MHz
6: 918.0 MHz
7: 921.0 MHz
8: 924.0 MHz
9: 927.0 MHz
1: -15 dBm
2: -10 dBm
3: -5 dBm
4: -3 dBm
5: -1 dBm
1: 1.2 kbit/s
2: 2.4 kbit/s
3: 4.8 kbit/s
4: 9.6 kbit/s
5: 19.2 kbit/s
RF channel and output power level can be set using the configuration commands ‘C’ and ‘P’
respectively. The data rate is fixed at 19.2 kbit/s. The default RF channel and output power
level can be set in the configuration memory by using the ‘M’ command setting
RF_CHANNEL and RF_POWER. The default values are used after power ON and RESET.
The default factory settings are shown in bold in the table above.
For more details on changing the RF channel, output power or data rate, refer to the RC232™
User Manual describing the configuration commands.
The use of RF frequencies and maximum allowed RF power is limited by national regulations.
The RC1040 and RC1080 are complying with the applicable directives within the European
Union. The RC1090 is pending approval under FCC for use in the US and Canada.
