Mechanical Dimensions
The module size is 12.7 x 25.4 x 3.5 mm.
1.0" / 25.4 mm
0.
5"
/
12
.7
m
m
1.0" / 25.4 mm
0.
5"
/
12
.7
m
m
Carrier Tape and Reel Specification
Carrier tape and reel is in accordance with EIA Specification 481.
Tape width Component
pitch
Hole pitch Reel
diameter
Units per
reel
44 mm 16 mm 4 mm 13” Max 1000
