MAX5062/MAX5063/MAX5064
125V/2A, High-Speed,
Half-Bridge MOSFET Drivers
16
______________________________________________________________________________________
MAX5064A/
MAX5064B
PWM IN
V
OUT
PGND
IN_H+
IN_L-
DH
DL
HS
BST
BBM
V
DD
IN_L+
IN_H-
R
BBM
AGND
C
BBM
V
DD
C
BST
C
DD
V
IN
= 125V
V
DD
8V TO 12.6V
Typical Operating Circuit
PART
TEMP RANGE
PIN-
PACKAGE
TOP
MARK
MAX5063AASA
-40°C to +125°C
8 SO
—
MAX5063BASA
-40°C to +125°C
8 SO
—
MAX5063CASA
-40°C to +125°C
8 SO-EP*
—
MAX5063DASA
-40°C to +125°C
8 SO-EP*
—
MAX5064AATC
-40°C to +125°C
12 TQFN
AAEF
MAX5064BATC
-40°C to +125°C
12 TQFN
AAEG
Ordering Information (continued)
PART
HIGH-SIDE DRIVER
LOW-SIDE DRIVER
LOGIC LEVELS
PIN COMPATIBLE
MAX5063AASA
Noninverting
Noninverting
TTL
HIP2101IB
MAX5063BASA
Noninverting
Inverting
TTL
—
MAX5063CASA
Noninverting
Noninverting
TTL
—
MAX5063DASA
Noninverting
Inverting
TTL
—
MAX5064AATC
Both Inverting and
Noninverting
Both Inverting and
Noninverting
CMOS (V
DD
/ 2)
—
MAX5064BATC
Both Inverting and
Noninverting
Both Inverting and
Noninverting
TTL
—
Selector Guide (continued)
Chip Information
TRANSISTOR COUNT: 790
PROCESS: HV BiCMOS
*EP = Exposed paddle.
