MAX5436–MAX5439
±15V, 128-Tap, Low-Drift Digital Potentiometers
_______________________________________________________________________________________ 3
PARAMETER SYMBOL CONDITIONS MIN TYP MAX UNITS
Input High Voltage V CC = 2.7V to 3.6V 2.0 V
Input Low Voltage V CC = 2.7V to 3.6V 0.6 V
Input Leakage Current ±1.0 µA
Input Capacitance 5.0 pF
DYNAMIC CHARACTERISTICS (Analog)
R HL = 50k Ω, midscale, V
H = 1.5V P-P ,
C WIPER = 20pF, voltage-divider mode
400
Wiper -3dB Bandwidth BW W
R HL = 100k Ω, midscale, V
H = 1.5V P-P ,
C WIPER = 20pF, voltage-divider mode
200
kHz
Wiper Settling Time t IL
C WIPER = 20pF, code 1 to code 127, settle
to 0.5LSB
5 µs
AMPLIFIER CHARACTERISTICS (Analog)
Input Bias Current I B 15 nA
Input Offset Voltage V OS
±6 mV
Offset-Voltage Temperature Drift V OSD 10 µV/°C
Input Offset Current I OS 2 nA
Unity-Gain Bandwidth UBW A C LOAD = 250pF 100 kHz
Slew Rate SR 0.25 V/µs
Large-Signal Voltage Gain A VO R LOAD = 100k Ω, V
OUT = ±14V 100 V/mV
Input Noise V
N
f = 1kHz 110 nV/ √Hz
Input Compliance CMR I V SS + 1 V DD - 2 V
Output Compliance CMR O I LOAD = ±5mA V SS + 1 V DD - 1 V
DC CMRR CMRR 68 dB
DC PSRR PSRR 70 dB
TIMING CHARACTERISTICS (Digital) (Note 5, Figure 3)
SCLK Clock Frequency f CLK 0 10 MHz
SCLK Clock Period t CP 100 ns
SCLK Pulse Width High t CH 40 ns
SCLK Pulse Width Low t CL 40 ns
CS Fall to SCLK Rise Setup Time t
CSS
40 ns
SCLK Rise to CS Rise Hold Time t CSH 10 ns
DIN Setup Time t DS 40 ns
DIN Hold Time t DH 0 ns
SCLK Rise to CS Fall Delay t CSO 10 ns
CS Rise to SCLK Rise Hold t CS1 40 ns
CS Pulse Width High t CSW 100 ns
POWER SUPPLIES
Positive Analog Supply Voltage V DD 0 31.5 V
Negative Analog Supply Voltage V SS -28.8 0 V
ELECTRICAL CHARACTERISTICS (continued)
(V DD = +15V, V SS = -15V, V CC = +5V, V H = V DD , V L = V SS , T A = -40°C to +85°C, unless otherwise noted. Typical values are at
T A = +25°C, unless otherwise noted.)
