MAX5436–MAX5439
±15V, 128-Tap, Low-Drift Digital Potentiometers
2 _______________________________________________________________________________________
ABSOLUTE MAXIMUM RATINGS
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.
V DD to GND, V SS = GND........................................-0.3V to +34V
V SS to GND, V DD = GND........................................-34V to +0.3V
V
DD
to V
SS
..............................................................-0.3V to +34V
V DD to V CC ........................................................-6.3V to +28.75V
V CC to V SS ..............................................................-0.3V to +34V
V CC to GND ..............................................................-0.3V to +6V
DIN, SCLK, CS, SHDN ...............................-0.3V to (V CC + 0.3V)
H, L, W, IN+, IN-, OUT .....................(V SS - 0.3V) to (V DD + 0.3V)
Maximum Continuous Current into H, L, and W
MAX5436–MAX5439.......................................................±1mA
Continuous Power Dissipation (T A = +70°C)
10-Pin µMAX (derate 6.94mW/°C above +70°C) .........556mW
14-Pin TSSOP (derate 9.1mW/°C above +70°C) .........727mW
Operating Temperature Range ...........................-40°C to +85°C
Junction Temperature ......................................................+150°C
Storage Temperature Range .............................-65°C to +150°C
Lead Temperature (soldering, 10s) .................................+300°C
ELECTRICAL CHARACTERISTICS
(V
DD
= +15V, V
SS
= -15V, V
CC
= +5V, V
H
= V
DD
, V
L
= V
SS
, T
A
= -40°C to +85°C, unless otherwise noted. Typical values are at
T A = +25°C, unless otherwise noted.)
PARAMETER SYMBOL CONDITIONS MIN TYP MAX UNITS
DC PERFORMANCE (Voltage-Divider Mode)
Resolution 2 N 128 Taps
Integral Nonlinearity INL (Note 1) ±1 LSB
Differential Nonlinearity DNL (Note 1) ±1 LSB
End-to-End Resistor Tempco TC R 35 ppm/°C
Ratiometric Resistor Tempco 5 ppm/°C
Full-Scale Error R HL = 50k Ω (MAX5436/MAX5438) -0.3 LSB
Zero-Scale Error R HL = 50k Ω (MAX5436/MAX5438) +0.3 LSB
Full-Scale Error R HL = 100k Ω (MAX5437/MAX5439) -0.15 LSB
Zero-Scale Error R HL = 100k Ω (MAX5437/MAX5439) +0.15 LSB
DC PERFORMANCE (Variable-Resistor Mode)
Resolution 2 N 128 Taps
Integral Nonlinearity INL (Note 2) ±1 LSB
Differential Nonlinearity DNL (Note 2) ±1 LSB
DC PERFORMANCE (Resistor Characteristics)
Wiper Resistance W R (Note 3) 0.9 2 k Ω
Wiper Capacitance W C Midscale 6 pF
MAX5437/MAX5439 75 100 125
End-to-End Resistance R HL
MAX5436/MAX5438 37.5 50 62.5
k Ω
DIGITAL INPUTS
Input High Voltage V CC = 4.75V to 5.25V (Note 4) 2.4 V
Input Low Voltage V CC = 4.75V to 5.25V 0.8 V
