MAX6965
9-Output LED Driver with Intensity Control
______________________________________________________________________________________ 19
Table 12. Output Intensity Registers
REGISTER DATA
REGISTER
ADDRESS
CODE
(HEX)
D7 D6 D5 D4 D3 D2 D1 D0
MSB LSB MSB LSB
OUTPUTS O1, O0 INTENSITY
R/ W
OUTPUT O1 INTENSITY OUTPUT O0 INTENSITY
Write output O1, O0 intensity 0
Read-back output O1, O0 intensity 1
O1I3 O1I2 O1I1 O1I0 O0I3 O0I2 O0I1 O0I0
Output O1 intensity duty cycle is 1/16 — 0 0 0 0 — — — —
Output O1 intensity duty cycle is 2/16 — 0 0 0 1 — — — —
Output O1 intensity duty cycle is 3/16 — 0 0 1 0 — — — —
— — — — — — — — — —
Output O1 intensity duty cycle is 14/16 — 1 1 0 1 — — — —
Output O1 intensity duty cycle is 15/16 — 1 1 1 0 — — — —
Output O1 intensity duty cycle is 16/16
(static logic level, no PWM)
— 1 1 1 1 — — — —
Output O0 intensity duty cycle is 1/16 — — — — — 0 0 0 0
Output O0 intensity duty cycle is 2/16 — — — — — 0 0 0 1
Output O0 intensity duty cycle is 3/16 — — — — — 0 0 1 0
— — — — — — — — — —
Output O0 intensity duty cycle is 14/16 — — — — — 1 1 0 1
Output O0 intensity duty cycle is 15/16 — — — — — 1 1 1 0
Output O0 intensity duty cycle is 16/16
(static logic level, no PWM)
—
0X10
— — — — 1 1 1 1
MSB LSB MSB LSB
OUTPUTS O3, O2 INTENSITY
OUTPUT O3 INTENSITY OUTPUT O2 INTENSITY
Write output O3, O2 intensity 0
Read-back output O3, O2 intensity 1
0x11
O3I3 O3I2 O3I1 O3I0 O2I3 O2I2 O2I1 O2I0
MSB LSB MSB LSB
OUTPUTS O5, O4 INTENSITY
OUTPUT O5 INTENSITY OUTPUT O4 INTENSITY
Write output O5, O4 intensity 0
Read-back output O5, O4 intensity 1
0x12
O5I3 O5I2 O5I1 O5I0 O4I3 O4I2 O4I1 O4I0
MSB LSB MSB LSB
OUTPUTS O7, O6 INTENSITY
OUTPUT O7 INTENSITY OUTPUT O6 INTENSITY
Write output O7, O6 intensity 0
Read-back output O7, O6 intensity 1
0x13
O7I3 O7I2 O7I1 O7I0 O6I3 O6I2 O6I1 O6I0
OUTPUT O8 INTENSITY See master, O8 intensity register (Table 11).
