MAX5471/MAX5472/MAX5474/MAX5475
32-Tap, Nonvolatile, Linear-Taper Digital
Potentiometers in SOT23
2
_______________________________________________________________________________________
ABSOLUTE MAXIMUM RATINGS
ELECTRICAL CHARACTERISTICS
(V
DD
= +2.7V to +5.25V, V
H
= V
DD
, V
L
= GND, T
A
= -40
°C to +85°C, unless otherwise noted. Typical values are at V
DD
= +5.0V, T
A
= +25
°C, unless otherwise noted.) (Note 1)
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.
V
DD
to GND ...........................................................-0.3V to +6.0V
All Other
Pins to GND .........-0.3V to the lower of (V
DD
+ 0.3V) or +6.0V
Maximum Continuous Current into H, L, and W
MAX5471/MAX5474 .....................................................
±1.3mA
MAX5472/MAX5475 .....................................................
±0.6mA
Continuous Power Dissipation (T
A
= +70
°C)
6-Pin SOT23 (derate 9.1mW/
°C above +70°C)............727mW
8-Pin SOT23 (derate 8.9mW/
°C above +70°C)............714mW
Operating Temperature Range ...........................-40
°C to +85°C
Junction Temperature ......................................................+150
°C
Storage Temperature Range .............................-60
°C to +150°C
Lead Temperature (soldering, 10s) .................................+300
°C
PARAMETER
SYMBOL
CONDITIONS
MIN
TYP
MAX
UNITS
DC PERFORMANCE
Resolution
N
32
Tap
MAX5471/MAX5474
37.5
50
62.5
End-to-End Resistance
MAX5472/MAX5475
75
100
125
k
Ω
End-to-End Resistance
Temperature Coefficient
TC
R
35
ppm/
°C
Ratiometric Resistance
Temperature Coefficient
5
ppm/
°C
Variable-resistor mode (Note 2)
±0.5
±1.0
Integral Nonlinearity
INL
Voltage-divider mode (MAX5474/MAX5475)
(Note 3)
±0.1
±0.5
LSB
Variable-resistor mode (Note 2)
±0.5
±1.0
Differential Nonlinearity
DNL
Voltage-divider mode (MAX5474/MAX5475)
(Note 3)
±0.1
±0.5
LSB
Full-Scale Error
MAX5474/MAX5475
-0.5
LSB
Zero-Scale Error
MAX5474/MAX5475
+0.5
LSB
Wiper Resistance
R
W
MAX5474/MAX5475 (Note 4)
600
1200
Ω
DIGITAL INPUTS (CS, U/D, INC) (Note 5)
V
DD
< 3.6V
0.7 x V
DD
Input High Voltage
V
IH
V
DD
≥ 3.6V
2.4
V
V
DD
< 3.6V
0.3 x V
DD
Input Low Voltage
V
IL
V
DD
≥ 3.6V
0.8
V
Input Current
I
IN
±0.1
±1
µA
DYNAMIC CHARACTERISTICS
MAX5471/MAX5474
400
Wiper -3dB Bandwidth (Note 6)
MAX5472/MAX5475
200
kHz
