MAX19993
Dual, SiGe, High-Linearity, 1200MHz to 1700MHz
Downconversion Mixer with LO Buffer/Switch
22
Chip Information
PROCESS: SiGe BiCMOS
Package Information
For the latest package outline information and land patterns,
go to
www.maxim-ic.com/packages
. Note that a “+”, “#”, or
“-” in the package code indicates RoHS status only. Package
drawings may show a different suffix character, but the drawing
pertains to the package regardless of RoHS status.
PACKAGE
TYPE
PACKAGE
CODE
OUTLINE
NO.
LAND
PATTERN
36 Thin QFN-EP
T3666+2
Table_1._Component_Values_(continued)
DESIGNATION
QTY
DESCRIPTION
COMPONENT_SUPPLIER
C10, C11, C12,
C19, C20, C21
6
150pF microwave capacitors (0603)
Murata Electronics North America, Inc.
L1, L2, L4, L5
4
330nH wire-wound high-Q inductors (0805)
Coilcraft, Inc.
L3, L6
2
0I resistors (0603). For improved RF-to-IF and
LO-to-IF isolation, contact factory for details.
Digi-Key Corp.
L7, L8
2
Additional tuning elements (0402, not used)
—
R1, R4
2
681I
±1% resistors (0402). Used for V
CC
_=_5.0V
applications. Larger values can be used to reduce
power at the expense of some performance loss.
Digi-Key Corp.
681I
±1% resistors (0402). Used for V
CC
_=_3.3V
applications.
R2, R5
2
1.82kI
±1% resistors (0402). Used for V
CC
_=_5.0V
applications. Larger values can be used to reduce
power at the expense of some performance loss.
Digi-Key Corp.
1.43kI
±1% resistors (0402). Used for V
CC
_=_3.3V
applications.
R3, R6
2
0I resistors (1206)
Digi-Key Corp.
T1, T2
2
4:1 transformers (200:50) TC4-1W-7A
Mini-Circuits
U1
1
MAX19993 IC (36 TQFN-EP)
Maxim Integrated Products, Inc.
