MAX19993
Dual, SiGe, High-Linearity, 1200MHz to 1700MHz
Downconversion Mixer with LO Buffer/Switch
17
Pin Configuration
EXPOSED PAD
EXPOSED PAD ON THE BOTTOM OF THE PACKAGE
1 2 3 4 5 6 7 8 9
10
11
12
13
14
15
16
17
18
V CC
IFD_SET
GND
IFD+
IFD-
IND_EXTD
V CC
LO_ADJ_D
N.C.
19 20 21 22 23 24 25 26 27
LO2 GND GND GND LOSEL GND V
CC
GND LO1
RFMAIN
TAPMAIN
GND V
CC
GND V
CC
GND
TAPDIV
RFDIV
28
29
30
31
32
33
34
35
36
N.C.
LO_ADJ_M
V CC
IND_EXTM
IFM-
IFM+
GND
IFM_SET
V CC
TQFN
(6mm × 6mm)
TOP VIEW
MAX19993
+
