Page 23

9363-OM (V1.2)

9363 PRODUCT MANUAL

2-5

Installation and Setup

Setting Up 9363 Network Remote Control

CAUTION

If card resists fully engaging in rear I/O module mating connector, check for
alignment and proper insertion in slot tracks. Damage to card and/or rear I/O
module may occur if improper card insertion is attempted.

Verify that the card is fully engaged in rear I/O module mating
connector.

Close the frame front access panel.

Connect the input and output cables as shown in Installing a Rear I/O
Module (p. 2-3).

Repeat steps 1 through 8 for other 9363 cards.

Note:

Frame 1 and Frame 2 reference signals are received by the card over a refer-
ence bus on the card frame, and not on any card rear I/O module connectors.
The frame has BNC connectors labeled REF 1 and REF 2 which receive the
reference signal from an external source such as a house distribution.

Note:

To remove a card, press down on the ejector tab to unseat the card from the
rear I/O module mating connector. Evenly draw the card from its slot.

10.

If network remote control is to be used for the frame and the frame has
not yet been set up for remote control, perform setup in accordance with
Setting Up 9363 Network Remote Control (p. 2-5).

Note:

If installing a card in a frame already equipped for, and connected to
DashBoard™, no network setup is required for the card. The card will be dis-
covered by DashBoard™ and be ready for use.

Setting Up 9363 Network Remote Control

Perform remote control setup in accordance with Cobalt

reference guide

“Remote Control User Guide” (PN 9000RCS-RM).

Note:

• If network remote control is to be used for the frame and the frame has not

yet been set up for remote control, Cobalt

reference guide Remote

Control User Guide (PN 9000RCS-RM) provides thorough information and
step-by-step instructions for setting up network remote control of
COMPASS™ cards using DashBoard™. (Cobalt

OGCP-9000 and

OGCP-9000/CC Remote Control Panel product manuals have complete
instructions for setting up remote control using a Remote Control Panel.)

Download a copy of this guide by clicking on the

Support>Reference Documents link at www.cobaltdigital.com and then
select DashBoard Remote Control Setup Guide as a download, or contact
Cobalt

as listed in Contact Cobalt Digital Inc. (p. 1-13).

• If installing a card in a frame already equipped for, and connected to

DashBoard™, no network setup is required for the card. The card will be dis-
covered by DashBoard™ and be ready for use.
