1
9363 Functional Description
1-6 9363 PRODUCT MANUAL 9363-OM (V1.2)
Table 1-1 9363 Output Formats
Input
Format
Output
Format/
Rate
Lock State
Output
Format/
Rate
Lock State
Output
Format/
Rate
Lock State
480i 5994,
1080i 5994
480i 5994 Genlock 1080 i5994 Genlock AES Genlock
720p 5994 Genlock 1080p 2997 Genlock Word Clock Genlock
720p 2997 Genlock 1080p 2398 Clock Lock
720p 2398 Clock Lock 1080pSF 2398 Clock Lock
576i 50,
1080i 50
576i 50 Genlock 1080 i50 Genlock AES Genlock
720p 60 Clock Lock 1080p 30 Clock Lock Word Clock Genlock
720p 50 Genlock 1080p 25 Genlock
720p 30 Clock Lock 1080p 24 Clock Lock
720p 25 Genlock 1080pSF 24 Clock Lock
720p 24 Clock Lock 1080i 60 Clock Lock
720p 5994,
1080p 2997
480i 5994 Field Lock 1080 i5994 Field Lock AES Genlock
720p 5994 Genlock 1080p 2997 Genlock Word Clock Genlock
720p 2997 Genlock 1080p 2398 Clock Lock
720p 2398 Clock Lock 1080pSF 2398 Clock Lock
720p 50,
1080p 25
576i 50 Field Lock 1080i 60 Clock Lock AES Genlock
720p 60 Clock Lock 1080 i50 Field Lock Word Clock Genlock
720p 50 Genlock 1080p 30 Clock Lock
720p 30 Clock Lock 1080p 25 Genlock
720p 25 Genlock 1080p 24 Clock Lock
720p 24 Clock Lock 1080pSF 24 Clock Lock
720p 60,
1080p 30
576i 50 Clock Lock 1080i 60 Field Lock AES Genlock
720p 60 Genlock 1080 i50 Clock Lock Word Clock Genlock
720p 50 Clock Lock 1080p 30 Genlock
720p 30 Genlock 1080p 25 Clock Lock
720p 25 Clock Lock 1080p 24 Clock Lock
720p 24 Clock Lock 1080pSF 24 Clock Lock
Notes: 1. Format/rates listed in bold indicate format/rates also available using Internal source.
2. “NTSC” and “PAL” in this manual informally refer to 480i 5994 and 575i 50 SD-SDI video formats, respectively.
