1

Technical Specifications

1-10

9363 PRODUCT MANUAL

9363-OM (V1.2)

Technical Specifications

Table 1-3 lists the technical specifications for the 9363 Multi-Format
Reference Generator card.

Table 1-3

Technical Specifications

Item

Characteristic

Part number, nomenclature

9363 Multi-Format Reference Generator

Installation/usage environment

Intended for installation and usage in frame meeting openGear™
modular system definition.

Power consumption

< 6 Watts maximum

Environmental:

Operating temperature:
Relative humidity (operating or storage):

32° – 104° F (0° – 40° C)
< 95%, non-condensing

Frame communication

10/100 Mbps Ethernet with Auto-MDIX.

Analog Video Output (Reference Output
Channels)

Standards Accommodated:

SMPTE 274M, 296M, and 170M
ITU-R BT.470-6 (PAL-B)

Number of Channels:

4x2 (with RM20-9363-A)
4X1 (with RM20-9363-A/S)

Signal Level:

1 Vp-p

DC Offset:

< 50 mV

Output Impedance:

75

Return Loss:

> 40 dB to 30 MHz

Signal Level:

1 Vp-p

Internal Reference Frequency Stability:

1ppm initial; 4.6ppm/10 years

Thermal Stability:

± 0.25ppm (0° to 70° C)
