9363-OM (V1.2)

9363 PRODUCT MANUAL

1-9

Introduction

9363 Functional Description

AES Audio Output Channel Status Data

Table 1-2 lists the channel status information that is encoded into the AES
audio data outputted by the 9363.

Note:

The AES channel status settings outputted by the card are non-configurable.

9363 Rear I/O Modules

The 9363 physically interfaces to system video connections at the rear of its
frame using a Rear I/O Module.

All inputs and outputs (except frame distributed reference signals

Frame Ref 1

and

Frame Ref 2

) shown in the 9363 Functional Block Diagram (Figure 1-1)

enter and exit the card via the card edge backplane connector. The
Rear I/O Module breaks out the 9363 card edge connections to BNC
connectors that interface with other components and systems in the signal
chain. See “Installation”, Chapter 2 for Rear I/O Module connections.

Table 1-2

AES Audio Output Channel Status Data

Byte

Bit/Function

Configured Setting

0

0 –
1 –
2-4 –
5 –
6-7 –

Professional or Consumer use of Channel Status Block
Normal Audio or Non-Normal Audio
Emphasis
Lock Indication
Sampling Rate

Professional (1)
Normal Audio (0)
No Emphasis (100)
Not Indicated (0)
48 kHZ (01)

1

0-3 –
4-7 –

Channel Mode
User Bit Mode

2-channel Mode (0001)
192-bit (0001)

2

0-2 –
3-5 –
6-7 –

Aux Bit Usage
Sample Word Length
Alignment Level

24-bit audio sample; aux bit audio (001)
24-bits (101)
Not Indicated (00)

3

0-7 – Multi-channel Modes

Undefined (0)

4

0-1 –
2 –
3-6 –
7 –

Digital Audio Reference Signal (DARS)
Reserved
Sampling Frequency
Sampling Frequency Scaling Flag

Not a reference (0)
0
Not Indicated (0000)
No Scaling (0)

5

0-7 – Reserved

Unused (0)

6-9

ASCII Source ID

Unused (0)

10-13

ASCII Destination ID

Unused (0)

14-17

Local Sample Address

Unused (0)

18-22

Time of Day

Unused (0)

22

0-7 – C Data Reliability

All status bytes marked as Reliable

23

0-7 – CRC

Calculated CRC
