3
Control and Display Descriptions
3-2 9305 PRODUCT MANUAL 9305-OM (V4.1)
Note: When a setting is changed, settings displayed on DashBoard™ (or a Remote
Control Panel) are the settings as effected by the 9305 card itself and
reported back to the remote control; the value displayed at any time is the
actual value as set on the card.
Function Submenu/Parameter Submenu Overview
The functions and related parameters available on the 9305 card are organized
into function submenus, which consist of parameter groups as shown below.
Figure 3-1 shows how the 9305 card and its submenus are organized, and also
provides an overview of how navigation is performed between cards, function
submenus, and parameters.
Figure 3-1 Function Submenu/Parameter Submenu Overview
9305
Submenu a Submenu b Submenu z • • •
Individual Parameters
Each submenu consists of groups of parameters
related to the function submenu. Using the “Embedded
Audio Group 1/2” function submenu example, the
individual parameters for this function consist of
various audio parameters such as Channel Gain,
Phase, and so on.
If using DashBoard™ or a Remote Control Panel, the
desired 9305 card is first selected.
The desired function submenu is next selected.
Function Submenus consist of parameter groups
related to a particular 9305 card function (for
example, “Embedded Audio Group 1/2”).
