9305-OM (V4.1)

9305 PRODUCT MANUAL

1-13

Introduction

Technical Specifications

Technical Specifications

Table 1-2 lists the technical specifications for the 9305 HD/SD-SDI
Embedded Audio Delay card.

Table 1-2

Technical Specifications

Item

Characteristic

Part number, nomenclature

9305 HD/SD-SDI Embedded Audio Delay

Installation/usage environment

Intended for installation and usage in frame meeting openGear™
modular system definition.

Power consumption

< 7 Watts maximum

Environmental:

Operating temperature:
Relative humidity (operating or storage):

32° – 104° F (0° – 40° C)
< 95%, non-condensing

Frame communication

10/100 Mbps Ethernet with Auto-MDIX.

Indicators

Card edge display and indicators as follows:

• 4-character alphanumeric display

• Input Channel LED indicators

Controls

Card edge switches as follows:

• Menu Enter pushbutton switch

• Menu exit pushbutton switch

• Up/down selection toggle switch

Internal Tone Generators

Four built-in tone generators, each configurable for 18 discrete
sine wave frequencies ranging from 50 Hz to 16 kHz.

Generator source signal level is equivalent to -20 dBu.

Serial Digital Video Input

Data Rates Supported:

SMPTE 292 HD-SDI: 1.485 Gbps or 1.485/1.001 Gbps

SMPTE 259M-C SD-SDI: 270 Mbps

Impedance:

75

terminating

Equalization (HD):

328 ft (100 m) Belden 1694A

Post-Processor Serial Digital Video
Outputs

Number of Outputs:

Four HD/SD-SDI BNC per IEC 60169-8 Amendment 2

Impedance:

75
