2
3) Remove the standard vacuum line and replace it with the provided silicone vacuum tube. Secure the end with a hose clamp
4) Install the Turbosmart Dual port BOV in the same orientation as the standard BOV. Secure the hose ends with the standard
hose clamps and insert the vacuum line into the vacuum port of the BOV securing it with the supplied spring clamp. Start the
engine and check for leaks around the piping.
Note:
The Dual port is supplied with a blanking plug for the vent to atmosphere side of the BOV to convert the BOV to full recirculation
mode. Simply unscrew the trumpet and screw in the supplied blanking plug. Alternatively, the blanking plug can be used to convert the
BOV into full vent to atmosphere mode by installing the blank onto the plumb back side. An additional 34mm hose blank (sold
separately) is required to block off the plumb back hole in the intake pipe.
Remove Push provided hose onto
vacuum supply barb
