PULSAR GTiR BLOW-OFF VALVE ADAPTOR INSTRUCTIONS
Turbosmart Pty Limited P.O.Box 264 Croydon, NSW, 2132 Australia ABN: 69 081 069 794
Ph: +(612) 9798 2866 Fx: +(612) 9798 2826 Email: [email protected]
PART NUMBER
FG-ADM-GTiR
Step 11. Undo and remove the two nuts securing the
factory BOV using a 12mm socket or spanner.
Step 12. Release the factory hose spring clamp with a
set of long nose pliers and remove the return hose from
the factory BOV.
Step 13. Undo the factory hose clamp securing the
turbo hose to the factory BOV using an 8 millimetre
socket. Disconnect the return hose from the factory
BOV.
Step 14. Remove the factory BOV.
Step 15. Insert the 34mm diameter end of the GTiR
Adaptor into the factory turbo hose. Secure it with the
50mm constant tension hose clamp supplied using a 7
mm socket or spanner.
Step 16. If using a Dual Port or Plumb Back, go to
step 17. Otherwise, blank off the return hose with the
29mm Turbosmart plug supplied. Secure the plug with
the factory hose spring clamp.
REMOVE
