28
tan δ ESR
Capacitance Case DCL
max. @ 100kHz
(μF) Size
Nemco Part No.
(μA) max.
(%) max. mΩ
2 V DC @ 85°C (1.3V @ 125°C)
3.3 R MCT3.3 / 2RM7500 0.5 6 7500
4.7 R MCT4.7 / 2RM7500 0.5 6 7500
6.8 R MCT6.8 / 2RM7500 0.5 6 7500
10.0 R MCT10 / 2RM7500 0.5 10 7500
3 V DC @ 85°C (2V @ 125°C)
2.2 R MCT2.2 / 3RM7500 0.5 6 7500
3.3 R MCT3.3 / 3RM7500 0.5 6 7500
4.7 R MCT4.7 / 3RM7500 0.5 6 7500
6.8 R MCT6.8 / 3RM7500 0.5 6 7500
10.0 R MCT10 / 3RM7500 0.5 10 7500
22.0 R MCT22 / 3RM7500 0.7 20 7500
4 V DC @ 85°C (2.7V @ 125°C)
1.5 R MCT1.5 / 4RM7500 0.5 6 7500
2.2 R MCT2.2 / 4RM7500 0.5 6 7500
3.3 R MCT3.3 / 4RM7500 0.5 6 7500
4.7 R MCT4.7 / 4RM7500 0.5 6 7500
6.8 R MCT6.8 / 4RM7500 0.5 8 7500
10.0 R MCT10 / 4RM7500 0.5 10 7500
15.0 R MCT15 / 4RM7500 0.6 20 7500
22.0 R MCT22 / 4RM5000 0.9 6 5000
22.0 R MCT22 / 4RM7500 0.9 20 7500
6.3 V DC @ 85°C (4V @ 125°C)
1.0 R MCT1 / 6RM7500 0.5 6 7500
1.5 R MCT1.5 / 6RM7500 0.5 6 7500
2.2 R MCT2.2 / 6RM5000 0.5 6 5000
2.2 R MCT2.2 / 6RM7500 0.5 6 7500
3.3 R MCT3.3 / 6RM7500 0.5 6 7500
4.7 R MCT4.7 / 6RM7500 0.5 8 7500
6.8 R MCT6.8 / 6RM7500 0.5 10 7500
10.0 R MCT10 / 6RM6000 0.6 10 6000
10.0 R MCT10 / 6RM4000 0.6 10 4000
15.0 R MCT15 / 6RM7500 0.9 20 7500
10 V DC @ 85°C (7V @ 125°C)
0.47 R MCT.47 / 10RM7500 0.5 6 7500
0.68 R MCT.68 / 10RM7500 0.5 6 7500
1.0 R MCT1 / 10RM5000 0.5 6 5000
1.0 R MCT1 / 10RM7500 0.5 6 7500
1.5 R MCT1.5 / 10RM7500 0.5 6 7500
2.2 R MCT2.2 / 10RM5000 0.5 6 5000
2.2 R MCT2.2 / 10RM7500 0.5 6 7500
3.3 R MCT3.3 / 10RM7500 0.5 8 7500
3.3 R MCT3.3 / 10RM5000 0.5 8 5000
4.7 R MCT4.7 / 10RM6000 0.5 10 6000
4.7 R MCT4.7 / 10RM5000 0.5 10 5000
6.8 R MCT6.8 / 10RM7500 0.7 20 7500
10.0 R MCT10 / 10RM7500 1.0 20 7500
10.0 R MCT10 / 10RM4000 1.0 20 4000
16 V DC @ 85°C (10V @ 125°C)
0.47 R MCT.47 / 16RM7500 0.5 6 7500
0.68 R MCT.68 / 16RM7500 0.5 6 7500
1.0 R MCT1 / 16RM7500 0.5 6 7500
2.2 R MCT2.2 / 16RM5000 0.5 10 5000
2.2 R MCT2.2 / 16RM7500 0.5 10 7500
Miniature Size
Surface Mount Tantalum Capacitors
MCT
nemco
NEMCO reserves the right to supply a higher voltage rating, tighter tolerance and / or lower ESR in the same case size, to the same reliability standards.
Available in M (+ 20%) tolerance only.
0603 FOOTPRINT / CASE SIZE R
tan δ ESR
Capacitance Case DCL
max. @ 100kHz
(μF) Size
Nemco Part No.
(μA) max.
(%) max. mΩ
2 V DC @ 85°C (1.3V @ 125°C)
3.3 P MCT3.3 / 2PM15000 0.5 8 15000
4.7 P MCT4.7 / 2PM15000 0.5 12 15000
6.8 P MCT6.8 / 2PM15000 0.5 6 15000
10.0 P MCT10 / 2PM15000 0.5 15 15000
3 V DC @ 85°C (2V @ 125°C)
2.2 P MCT2.2 / 3PM15000 0.5 6 15000
3.3 P MCT3.3 / 3PM15000 0.5 8 15000
4.7 P MCT4.7 / 3PM 8000 0.5 12 8000
4.7 P MCT4.7 / 3PM15000 0.5 12 15000
6.3 V DC @ 85°C (4V @ 125°C)
1.0 P MCT1.0 / 6PM15000 0.5 6 15000
2.2 P MCT2.2 / 6PM 8000 0.5 8 8000
2.2 P MCT2.2 / 6PM15000 0.5 8 15000
10 V DC @ 85°C (7V @ 125°C)
0.47 P MCT.47 / 10PM15000 0.5 6 15000
0.47 P MCT.47 / 10PM25000 0.5 6 25000
0.68 P MCT.68 / 10PM15000 0.5 8 15000
1.0 P MCT1 / 10PM15000 0.5 6 15000
0402 FOOTPRINT / CASE SIZE P
