Nemco Electronics Marking User Manual
Marking, C4μ7, Date code system

Nemco surface mount tantalum capacitors are marked by laser on the top surface. The positive (+) end of the body has a
videcon readable bar marking for improved polarity identification. Space permitting, with the exception of MCT miniature
surface mount series, marking shall consist of:
l
Capacitance in
μfd
l
Voltage or voltage code (+85°C Vr)
l
Polarity Bar (+)
l
Date Code (Not available on: TB, CGT, MCT, PCT XL case size, LSR XL case size)
Case Sizes C, CL, D, DL, H, Z
Radial dipped tantalum capacitors are marked by laser
on the capacitor body. The positive (+) lead of the
capacitor has a polarity stripe for improved recognition.
Marking
Case Size P, R
Maximum ESR ratings in milliohms is
marked only for case sizes C, D and H.
C4μ7
Date Code
Voltage Code
Case Sizes XL, A, AL, B, BL
C4μ7 = 4.7 μfd / 16V
μ
Represents a
decimal point in
the capacitance
value.
Voltage
Polarity Bar (+)
Capacitance
Polarity (+)
Polarity (+)
Polarity (+)
Voltage
Capacitance
Polarity (+)
Voltage
Capacitance
Case Sizes C, CL, D, DL, H, Z
Due to small size, only polarity identification
appears on the component
μ
Represents a decimal point
in the capacitance value.
Examples:
μ1 = .1μfd
1
μ0 = 1μfd
10
μ = 10μfd
MCT and CGT Series
TB Series
PCT Series
LSR Series
PCT / LSR Series
Voltage VDC
4V
6.3V
10V
16V
20V
25V
35V
50V
Voltage Code
G
J
A
C
D
E
V
T
Date Code System
January
February
March
April
May
June
1
2
3
4
5
6
July
August
September
October
November
December
7
8
9
0
N
D
The Nemco date code uses a two character system.
The first character defines the year of manufacture.
The second character defines the month of manufacture.
examples: W3 = March 2008
VN = November 2007
Month
Year
2002
2003
2004
2005
2006
2007
2008
2009
2010
2011
2012
2013
P
R
S
T
U
V
W
X
A
B
C
D
