Nemco, Low profile surface mount tantalum capacitors, 16 v dc – Nemco Electronics Full Catalog User Manual
Page 14: 85°c, 20 v dc, 25 v dc, 35 v dc, 50 v dc, 10 v dc, 125°c)
14
tan
δ
ESR
Capacitance
Case
DCL
max.
@ 100Khz
(
μF)
Size
Nemco Part No.
(
μA) max.
(%)
max. (
Ω)
16 V DC
@
85°C
(10 V DC
@
125°C)
0.68
XL
PCT.68 / 16XL _
0.5
4
25.0
0.68
AL
PCT.68 / 16AL _
0.5
4
25.0
1.0
XL
PCT1
/ 16XL _
0.5
4
20.0
1.0
AL
PCT1
/ 16AL _
0.5
4
15.0
1.0
BL
PCT1
/ 16BL _
0.5
4
5.0
1.5
XL
PCT1.5 / 16XL _
0.5
6
10.0
1.5
AL
PCT1.5 / 16AL _
0.5
6
12.0
2.2
XL
PCT2.2 / 16XL _
0.5
6
6.5
2.2
AL
PCT2.2 / 16AL _
0.5
6
6.0
2.2
BL
PCT2.2 / 16BL _
0.5
6
6.5
3.3
XL
PCT3.3 / 16XL _
0.5
8
5.0
3.3
AL
PCT3.3 / 16AL _
0.5
6
5.0
3.3
BL
PCT3.3 / 16BL _
0.5
6
5.0
4.7
AL
PCT4.7 / 16AL _
0.8
8
4.5
4.7
BL
PCT4.7 / 16BL _
0.8
6
4.5
6.8
AL
PCT6.8 / 16AL _
1.1
8
2.4
6.8
BL
PCT6.8 / 16BL _
1.1
6
3.5
10.0
BL
PCT10
/ 16BL _
1.6
8
2.2
10.0
CL
PCT10
/ 16CL _
1.6
6
2.0
15.0
BL
PCT15
/ 16BL _
2.4
6
2.0
15.0
CL
PCT15
/ 16CL _
2.4
6
0.7
22.0
CL
PCT22
/ 16CL _
3.5
6
1.6
33.0
CL
PCT33
/ 16CL _
5.3
6
1.5
33.0
DL
PCT33
/ 16DL _
5.3
6
0.9
47.0
CL
PCT47
/ 16CL _
7.5
6
0.4
47.0
DL
PCT47
/ 16DL _
7.5
6
0.7
68.0
DL
PCT68
/ 16DL _
10.9
6
0.9
100.0
DL
PCT100 / 16DL _
16.0
8
0.9
150.0
DL
PCT150 / 16DL _
24.0
15
0.3
20 V DC
@
85°C
(13 V DC
@
125°C)
0.1
XL
PCT.1
/ 20XL _
0.5
4
25.0
0.1
AL
PCT.1
/ 20AL _
0.5
4
25.0
0.15
XL
PCT.15 / 20XL _
0.5
4
25.0
0.15
AL
PCT.15 / 20AL _
0.5
4
25.0
0.22
XL
PCT.22 / 20XL _
0.5
4
25.0
0.22
AL
PCT.22 / 20AL _
0.5
4
25.0
0.33
XL
PCT.33 / 20XL _
0.5
4
25.0
0.33
AL
PCT.33 / 20AL _
0.5
4
25.0
0.47
XL
PCT.47 / 20XL _
0.5
4
25.0
0.47
AL
PCT.47 / 20AL _
0.5
4
25.0
0.68
XL
PCT.68 / 20XL _
0.5
4
20.0
0.68
AL
PCT.68 / 20AL _
0.5
4
25.0
0.68
BL
PCT.68 / 20BL _
0.5
4
15.0
1.0
XL
PCT1
/ 20XL _
0.5
4
20.0
1.0
AL
PCT1
/ 20AL _
0.5
4
12.0
1.0
BL
PCT1
/ 20BL _
0.5
4
9.0
1.5
XL
PCT1.5 / 20XL _
0.5
6
9.6
1.5
AL
PCT1.5 / 20AL _
0.5
6
5.4
1.5
BL
PCT1.5 / 20BL _
0.5
6
6.5
2.2
XL
PCT2.2 / 20XL _
0.5
6
6.0
2.2
AL
PCT2.2 / 20AL _
0.5
6
4.5
2.2
BL
PCT2.2 / 20BL _
0.5
6
6.0
3.3
BL
PCT3.3 / 20BL _
0.7
6
3.0
4.7
BL
PCT4.7 / 20BL _
0.9
6
3.0
6.8
BL
PCT6.8 / 20BL _
1.4
6
2.6
10.0
CL
PCT10
/ 20CL _
2.0
6
1.9
15.0
CL
PCT15
/ 20CL _
3.0
6
1.7
22.0
CL
PCT22
/ 20CL _
4.4
6
1.6
22.0
DL
PCT22
/ 20DL _
4.4
6
0.9
33.0
DL
PCT33
/ 20DL _
6.6
6
0.6
47.0
DL
PCT47
/ 20DL _
9.4
6
0.9
68.0
DL
PCT68
/ 20DL _
13.6
6
0.9
tan
δ
ESR
Capacitance
Case
DCL
max.
@ 100Khz
(
μF)
Size
Nemco Part No.
(
μA) max.
(%)
max. (
Ω)
25 V DC
@
85°C
(17 V DC
@
125°C)
0.15
XL
PCT.15 / 25XL _
0.5
4
24.0
0.22
XL
PCT.22 / 25XL _
0.5
4
21.0
0.33
XL
PCT.33 / 25XL _
0.5
4
17.0
0.47
XL
PCT.47 / 25XL _
0.5
4
15.0
0.47
AL
PCT.47 / 25AL _
0.5
4
14.0
0.68
XL
PCT.68 / 25XL _
0.5
4
13.0
0.68
AL
PCT.68 / 25AL _
0.5
4
10.0
1.0
XL
PCT1
/ 25XL _
0.5
4
8.0
1.0
AL
PCT1
/ 25AL _
0.5
4
8.0
1.5
AL
PCT1.5 / 25AL _
0.5
6
5.4
1.5
BL
PCT1.5 / 25BL _
0.5
6
5.0
2.2
BL
PCT2.2 / 25BL _
0.6
6
4.5
3.3
BL
PCT3.3 / 25BL _
0.8
6
3.5
3.3
CL
PCT3.3 / 25CL _
0.8
6
1.6
4.7
BL
PCT4.7 / 25BL _
1.2
6
3.1
4.7
CL
PCT4.7 / 25CL _
1.2
6
1.2
6.8
CL
PCT6.8 / 25CL _
1.7
6
2.0
10.0
CL
PCT10
/ 25CL _
2.5
6
1.8
15.0
DL
PCT15
/ 25DL _
3.8
6
1.0
22.0
DL
PCT22
/ 25DL _
5.5
6
0.9
33.0
DL
PCT33
/ 25DL _
8.3
6
0.5
47.0
DL
PCT47
/ 25DL _
11.8
6
0.9
35 V DC
@
85°C
(23 V DC
@
125°C)
0.1
XL
PCT.1
/ 35XL _
0.5
4
29.0
0.1
AL
PCT.1
/ 35AL _
0.5
4
24.0
0.15
XL
PCT.15 / 35XL _
0.5
4
24.0
0.15
AL
PCT.15 / 35AL _
0.5
4
21.0
0.22
XL
PCT.22 / 35XL _
0.5
4
21.0
0.22
AL
PCT.22 / 35AL _
0.5
4
18.0
0.33
XL
PCT.33 / 35XL _
0.5
4
17.0
0.33
AL
PCT.33 / 35AL _
0.5
4
15.0
0.47
XL
PCT.47 / 35XL _
0.5
4
15.0
0.47
AL
PCT.47 / 35AL _
0.5
4
12.0
0.47
BL
PCT.47 / 35BL _
0.5
4
10.0
0.68
AL
PCT.68 / 35AL _
0.5
4
8.0
0.68
BL
PCT.68 / 35BL _
0.5
4
8.0
1.0
AL
PCT1
/ 35AL _
0.5
4
7.5
1.0
BL
PCT1
/ 35BL _
0.5
4
6.5
1.5
BL
PCT1.5 / 35BL _
0.5
6
5.2
2.2
BL
PCT2.2 / 35BL _
0.8
6
4.2
3.3
CL
PCT3.3 / 35CL _
1.2
6
1.6
4.7
CL
PCT4.7 / 35CL _
1.6
6
2.2
6.8
DL
PCT6.8 / 35DL _
2.3
6
0.9
10.0
DL
PCT10
/ 35DL _
3.5
6
1.0
15.0
DL
PCT15
/ 35DL _
5.3
6
0.6
22.0
DL
PCT22
/ 35DL _
7.7
6
0.5
50 V DC
@
85°C
(33 V DC
@
125°C)
0.1
AL
PCT.1
/ 50AL _
0.5
4
19.0
0.15
AL
PCT.15 / 50AL _
0.5
4
16.0
0.22
AL
PCT.22 / 50AL _
0.5
4
13.0
0.33
AL
PCT.33 / 50AL _
0.5
4
11.0
0.33
BL
PCT.33 / 50BL _
0.5
4
11.0
0.47
AL
PCT.47 / 50AL _
0.5
4
9.5
0.47
BL
PCT.47 / 50BL _
0.5
4
9.5
1.0
CL
PCT1
/ 50CL _
0.5
6
4.4
1.5
CL
PCT1.5 / 50CL _
0.8
6
3.1
3.3
DL
PCT3.3 / 50DL _
1.7
4
1.7
4.7
DL
PCT4.7 / 50DL _
2.4
6
1.2
6.8
DL
PCT6.8 / 50DL _
3.4
6
0.9
Low Profile
Surface Mount Tantalum Capacitors
PCT
nemco
NEMCO reserves the right to supply a higher voltage rating, tighter tolerance and / or lower ESR in the same case size, to the same reliability standards.
_
Insert tolerance M (+20%) or K(+10%) to complete the Nemco part number
