Nemco Electronics Full Catalog - Manual (Page 21)

δ
μ μ
Ω
20 V DC @ 85°C cont. (13 V DC @ 125°C)
10.0 B 500 LSR10 / 20B _ 500 2.0 6 412 371 165
10.0 B 1000 LSR10 / 20B _ 1000 2.0 6 292 262 117
10.0 C 500 LSR10 / 20C _ 500 2.0 6 469 422 188
10.0 C 700 LSR10 / 20C _ 700 2.0 6 396 357 159
15.0 B 500 LSR15 / 20B _ 500 3.0 6 412 371 165
15.0 C 400 LSR15 / 20C _ 400 3.0 6 524 472 210
15.0 C 450 LSR15 / 20C _ 450 3.0 6 494 445 198
22.0 B 400 LSR22 / 20B _ 400 4.4 6 461 415 184
22.0 B 600 LSR22 / 20B _ 600 4.4 6 376 339 151
22.0 C 100 LSR22 / 20C _ 100 4.4 6 1049 944 420
22.0 C 150 LSR22 / 20C _ 150 4.4 6 856 771 343
22.0 C 400 LSR22 / 20C _ 400 4.4 6 524 472 210
22.0 D 200 LSR22 / 20D _ 200 4.4 6 866 779 346
22.0 D 300 LSR22 / 20D _ 300 4.4 6 707 636 283
33.0 C 300 LSR33 / 20C _ 300 6.6 6 606 545 242
33.0 D 100 LSR33 / 20D _ 100 6.6 6 1225 1102 490
33.0 D 200 LSR33 / 20D _ 200 6.6 6 866 779 346
47.0 D 45 LSR47 / 20D _ 45 9.4 8 2380 2142 952
47.0 D 55 LSR47 / 20D _ 55 9.4 8 2153 1938 861
47.0 D 75 LSR47 / 20D _ 75 9.4 6 1414 1273 566
47.0 D 100 LSR47 / 20D _ 100 9.4 6 1225 1102 490
47.0 D 200 LSR47 / 20D _ 200 9.4 6 866 779 346
47.0 H 70 LSR47 / 20H _ 70 9.4 6 1535 1382 614
47.0 H 125 LSR47 / 20H _ 125 9.4 6 1149 1034 460
47.0 H 150 LSR47 / 20H _ 150 9.4 6 1049 944 420
47.0 H 200 LSR47 / 20H _ 200 9.4 6 908 817 363
47.0 H 250 LSR47 / 20H _ 250 9.4 6 812 731 325
68.0 D 70 LSR68 / 20D _ 70 13.6 6 1464 1317 586
68.0 D 150 LSR68 / 20D _ 150 13.6 6 1000 900 400
68.0 D 200 LSR68 / 20D _ 200 13.6 6 866 779 346
68.0 D 300 LSR68 / 20D _ 300 13.6 6 707 636 283
68.0 H 125 LSR68 / 20H _ 125 13.6 6 1149 1034 460
68.0 H 150 LSR68 / 20H _ 150 13.6 6 1049 944 420
68.0 H 200 LSR68 / 20H _ 200 13.6 6 908 817 363
100.0 D 85 LSR100 / 20D _ 85 20.0 6 1328 1196 531
100.0 D 100 LSR100 / 20D _ 100 20.0 6 1225 1102 490
100.0 D 150 LSR100 / 20D _ 150 20.0 6 1000 900 400
100.0 H 35 LSR100 / 20H _ 35 20.0 6 2777 2500 1111
100.0 H 45 LSR100 / 20H _ 45 20.0 6 2449 2205 980
100.0 H 100 LSR100 / 20H _ 100 20.0 6 1285 1156 514
100.0 H 150 LSR100 / 20H _ 150 20.0 6 1049 944 420
100.0 H 200 LSR100 / 20H _ 200 20.0 6 908 817 363
100.0 Z 60 LSR100 / 20Z _ 60 20.0 8 2041 1837 816
100.0 Z 85 LSR100 / 20Z _ 85 20.0 8 1715 1543 686
100.0 Z 100 LSR100 / 20Z _ 100 20.0 8 1581 1423 632
100.0 Z 200 LSR100 / 20Z _ 200 20.0 8 1118 1006 447
150.0 H 35 LSR150 / 20H _ 35 30.0 10 2777 2500 1111
150.0 Z 80 LSR150 / 20Z _ 80 30.0 8 1768 1591 707
25 V DC @ 85°C (17 V DC @ 125°C)
0.47 A 7000 LSR.47 / 25A _ 7000 0.5 4 104 93 41
0.68 A 6000 LSR.68 / 25A _ 6000 0.5 4 112 101 45
1.0 A 4000 LSR1.0 / 25A _ 4000 0.5 4 137 123 55
1.5 A 3000 LSR1.5 / 25A _ 3000 0.5 6 158 142 63
1.5 B 1800 LSR1.5 / 25B _ 1800 0.5 6 217 196 87
2.2 B 900 LSR2.2 / 25B _ 900 0.6 6 307 277 123
2.2 B 1200 LSR2.2 / 25B _ 1200 0.6 6 266 240 106
2.2 B 2500 LSR2.2 / 25B _ 2500 0.6 6 184 166 74
3.3 A 1000 LSR3.3 / 25A _ 1000 0.8 6 274 246 110
3.3 A 1500 LSR3.3 / 25A _ 1500 0.8 6 224 201 89
3.3 B 750 LSR3.3 / 25B _ 750 0.8 6 337 303 135
3.3 B 1500 LSR3.3 / 25B _ 1500 0.8 6 238 214 95
3.3 B 2000 LSR3.3 / 25B _ 2000 0.8 6 206 186 82
4.7 B 700 LSR4.7 / 25B _ 700 1.2 6 348 314 139
4.7 B 900 LSR4.7 / 25B _ 900 1.2 6 307 277 123
_ Insert tolerance M (+20%) or K(+10%) to complete the Nemco part number
NEMCO reserves the right to supply a higher voltage rating, tighter tolerance and / or lower ESR in the same case size, to the same reliability standards.
21
ESR tan δ Max. Ripple Current
Capacitance Case DCL
@ 100Khz max. @ 100kHz mA
μF Size Nemco Part No. μA max.
max. m
Ω
(%)
(milliamps)
(microfarads) (milliohms) (microamps)
25°C 85°C 125°C
PART NUMBERS & SPECIFICATIONS
Low ESR
Surface Mount Tantalum Capacitors
LSR nemco
