Nemco Electronics Full Catalog - Manual (Page 25)

δ
μ μ
Ω
4 V DC @ 85°C (2.7 V DC @ 125°C)
10.0 XL 3000 LSR10 / 4XL _3000 0.5 6 135 122 54
100.0 CL 100 LSR100 / 4CL _ 100 4.0 6 949 854 379
220.0 DL 40 LSR220 / 4DL _ 40 8.8 8 1768 1591 707
220.0 DL 50 LSR220 / 4DL _ 50 8.8 8 1581 1423 632
220.0 DL 75 LSR220 / 4DL _ 75 8.8 8 1291 1162 516
6.3 V DC @ 85°C (4 V DC @ 125°C)
2.2 XL 7000 LSR2.2 / 6XL _7000 0.5 6 89 80 35
4.7 AL 4000 LSR4.7 / 6AL _4000 0.5 6 127 115 51
10.0 XL 1000 LSR10 / 6XL _1000 0.6 8 235 211 94
10.0 XL 1500 LSR10 / 6XL _1500 0.6 8 191 172 77
10.0 XL 3000 LSR10 / 6XL _3000 0.6 8 135 122 54
10.0 BL 1000 LSR10 / 6BL _1000 0.6 6 283 255 113
22.0 AL 900 LSR22 / 6AL _ 900 1.4 10 269 242 107
33.0 BL 800 LSR33 / 6BL _ 800 2.1 10 316 285 126
47.0 BL 1200 LSR47 / 6BL _1200 2.8 10 258 232 103
68.0 CL 110 LSR68 / 6CL _ 110 4.3 6 905 814 362
68.0 CL 125 LSR68 / 6CL _ 125 4.3 6 849 764 339
68.0 CL 250 LSR68 / 6CL _ 250 4.3 6 600 540 240
100.0 CL 100 LSR100 / 6CL _ 100 6.3 6 949 854 379
100.0 CL 150 LSR100 / 6CL _ 150 6.3 6 775 697 310
100.0 DL 100 LSR100 / 6DL _ 100 6.3 6 1118 1006 447
150.0 DL 40 LSR150 / 6DL _ 40 9.5 6 1768 1591 707
150.0 DL 50 LSR150 / 6DL _ 50 9.5 6 1581 1423 632
220.0 DL 30 LSR220 / 6DL _ 30 13.2 6 2646 2381 1058
220.0 DL 100 LSR220 / 6DL _ 100 13.9 8 1118 1006 447
220.0 DL 150 LSR220 / 6DL _ 150 13.9 10 913 822 365
330.0 DL 100 LSR330 / 6DL _ 100 20.8 12 1118 1006 447
330.0 DL 150 LSR330 / 6DL _ 150 20.8 12 913 822 365
470.0 DL 150 LSR470 / 6DL _ 150 28.2 20 913 822 365
10 V DC @ 85°C (7 V DC @ 125°C)
1.0 XL 9000 LSR1 / 10XL _9000 0.5 4 78 70 31
3.3 BL 1500 LSR3.3 / 10BL _1500 0.5 6 231 208 92
4.7 XL 3000 LSR4.7 / 10XL _3000 0.5 6 135 122 54
4.7 XL 5000 LSR4.7 / 10XL _5000 0.5 6 105 94 42
6.8 BL 1800 LSR6.8 / 10BL _1800 0.7 6 211 190 84
10.0 AL 900 LSR10 / 10BL _ 900 1.0 8 269 242 107
10.0 BL 1000 LSR10 / 10BL _1000 1.0 6 283 255 113
10.0 BL 2000 LSR10 / 10BL _2000 1.0 6 200 180 80
15.0 BL 1200 LSR15 / 10BL _1200 1.5 8 258 232 103
22.0 BL 800 LSR22 / 10BL _ 800 2.2 8 316 285 126
33.0 CL 350 LSR33 / 10CL _ 350 3.3 6 507 456 203
47.0 CL 125 LSR47 / 10CL _ 125 4.7 6 849 764 339
47.0 CL 150 LSR47 / 10CL _ 150 4.7 6 775 697 310
47.0 CL 250 LSR47 / 10CL _ 250 4.7 6 600 540 240
68.0 CL 100 LSR68 / 10CL _ 100 6.8 6 949 854 379
68.0 CL 150 LSR68 / 10CL _ 150 6.8 6 775 697 310
68.0 DL 100 LSR68 / 10DL _ 100 6.8 6 1118 1006 447
68.0 DL 200 LSR68 / 10DL _ 200 6.8 6 791 712 316
100.0 CL 150 LSR100 / 10CL _ 150 10.0 6 775 697 310
100.0 DL 45 LSR100 / 10DL _ 45 10.0 8 2160 1944 864
100.0 DL 100 LSR100 / 10DL _ 100 10.0 6 1118 1006 447
100.0 DL 150 LSR100 / 10DL _ 150 10.0 6 913 822 365
100.0 DL 200 LSR100 / 10DL _ 200 10.0 6 791 712 316
150.0 DL 45 LSR150 / 10DL _ 45 15.0 8 2160 1944 864
150.0 DL 100 LSR150 / 10DL _ 100 15.0 6 1118 1006 447
150.0 DL 150 LSR150 / 10DL _ 150 15.0 6 913 822 365
150.0 DL 200 LSR150 / 10DL _ 200 15.0 6 791 712 316
220.0 DL 100 LSR220 / 10DL _ 100 22.0 10 1118 1006 447
220.0 DL 150 LSR220 / 10DL _ 150 22.0 10 913 822 365
220.0 DL 200 LSR220 / 10DL _ 200 22.0 10 791 712 316
_ Insert tolerance M (+20%) or K(+10%) to complete the Nemco part number
NEMCO reserves the right to supply a higher voltage rating, tighter tolerance and / or lower ESR in the same case size, to the same reliability standards.
ESR tan
δ
Max. Ripple Current
Capacitance Case DCL
@ 100Khz max. @ 100kHz mA
μF
Size Nemco Part No. μA max.
max. m
Ω
(%) (milliamps)
(microfarads) (milliohms) (microamps)
25°C 85°C 125°C
PART NUMBERS & SPECIFICATIONS
25
Low Profile
Surface Mount Tantalum Capacitors
LSR
