Page 10: 3 v dc, 10 v dc, 16 v dc, 7 v dc, 125°c)
10
tan
δ
ESR
Capacitance
Case
DCL
max.
@ 100kHz
(
μF)
Size
Nemco Part No.
(
μA) max.
(%)
max. (
Ω)
4 V DC
@
85°C
(2.7 V DC
@
125°C)
33.0
A
PCT33
/ 4A _
1.3
6
3.0
47.0
A
PCT47
/ 4A _
1.9
8
2.6
68.0
A
PCT68
/ 4A _
2.7
10
1.5
68.0
B
PCT68
/ 4B _
2.7
6
1.8
100.0
A
PCT100 / 4A _
4.0
30
1.4
100.0
B
PCT100 / 4B _
4.0
8
0.9
150.0
B
PCT150 / 4B _
6.0
10
1.5
150.0
C
PCT150 / 4C _
6.0
6
0.3
220.0
B
PCT220 / 4B _
8.8
12
1.1
220.0
C
PCT220 / 4C _
8.8
8
1.2
220.0
D
PCT220 / 4D _
8.8
8
0.9
330.0
C
PCT330 / 4C _
13.2
8
0.3
330.0
D
PCT330 / 4D _
13.2
8
0.9
470.0
C
PCT470 / 4C _
18.8
14
0.3
470.0
D
PCT470 / 4D _
18.8
12
0.9
470.0
H
PCT470 / 4H _
18.8
10
0.5
680.0
D
PCT680 / 4D _
27.2
14
0.5
680.0
H
PCT680 / 4H _
27.2
14
0.9
1000.0
D
PCT1000 /4D _
40.0
60
0.2
1000.0
H
PCT1000 /4H _
40.0
14
0.4
1500.0
H
PCT1500 /4H _
60.0
30
0.2
6.3 V DC
@
85°C
(4 V DC
@
125°C)
10.0
A
PCT10
/ 6A _
0.6
6
4.0
15.0
A
PCT15
/ 6A _
0.9
6
3.5
15.0
B
PCT15
/ 6B _
1.0
6
2.5
22.0
A
PCT22
/ 6A _
1.4
6
3.0
22.0
B
PCT22
/ 6B _
1.4
6
2.5
33.0
A
PCT33
/ 6A _
2.1
8
3.2
33.0
B
PCT33
/ 6B _
2.1
6
2.2
33.0
C
PCT33
/ 6C _
2.1
6
1.8
47.0
A
PCT47
/ 6A _
2.8
10
1.6
47.0
B
PCT47
/ 6B _
3.0
6
2.0
47.0
C
PCT47
/ 6C _
3.0
6
1.6
68.0
B
PCT68
/ 6B _
4.0
8
0.9
68.0
C
PCT68
/ 6C _
4.3
6
1.5
68.0
D
PCT68
/ 6D _
4.3
6
0.9
100.0
B
PCT100 / 6B _
6.3
10
1.7
100.0
C
PCT100 / 6C _
6.3
6
0.9
100.0
D
PCT100 / 6D _
6.3
6
0.9
150.0
B
PCT150 / 6B _
9.5
10
1.2
150.0
C
PCT150 / 6C _
9.5
6
1.3
150.0
D
PCT150 / 6D _
9.5
6
0.9
220.0
C
PCT220 / 6C _
13.9
8
1.2
220.0
D
PCT220 / 6D _
13.9
8
0.4
220.0
H
PCT220 / 6H _
13.9
8
0.4
330.0
C
PCT330 / 6C _
19.8
12
0.5
330.0
D
PCT330 / 6D _
20.8
8
0.4
330.0
H
PCT330 / 6H _
20.8
8
0.4
470.0
D
PCT470 / 6D _
28.0
12
0.4
470.0
H
PCT470 / 6H _
28.0
10
0.4
680.0
H
PCT680 / 6H _
42.8
10
0.5
1000.0
H
PCT1000 /6H _
60.0
20
0.2
1000.0
Z
PCT1000 /6Z _
60.0
16
0.4
tan
δ
ESR
Capacitance
Case
DCL
max.
@ 100kHz
(
μF)
Size
Nemco Part No.
(
μA) max.
(%)
max. (
Ω)
10 V DC
@
85°C
(7 V DC
@
125°C)
2.2
A
PCT2.2 / 10A _
0.5
6
7.0
4.7
A
PCT4.7 / 10A _
0.5
6
5.0
6.8
A
PCT6.8 / 10A _
0.7
6
4.0
6.8
B
PCT6.8 / 10B _
0.7
6
3.0
10.0
A
PCT10
/ 10A _
1.0
6
3.0
10.0
B
PCT10
/ 10B _
1.0
6
2.5
15.0
A
PCT15
/ 10A _
1.5
6
3.2
15.0
B
PCT15
/ 10B _
1.5
6
2.8
22.0
A
PCT22
/ 10A _
2.2
8
3.0
22.0
B
PCT22
/ 10B _
2.2
6
2.4
22.0
C
PCT22
/ 10C _
2.2
6
1.8
33.0
A
PCT33
/ 10A _
3.3
8
1.7
33.0
B
PCT33
/ 10B _
3.3
6
1.8
33.0
C
PCT33
/ 10C _
3.3
6
1.6
47.0
B
PCT47
/ 10B _
4.7
8
1.0
47.0
C
PCT47
/ 10C _
4.7
6
1.2
47.0
D
PCT47
/ 10D _
4.7
6
0.9
68.0
B
PCT68
/ 10B _
6.8
6
1.4
68.0
C
PCT68
/ 10C _
6.8
6
1.3
68.0
D
PCT68
/ 10D _
6.8
6
0.9
100.0
B
PCT100 / 10B _
10.0
8
1.4
100.0
C
PCT100 / 10C _
10.0
8
1.2
100.0
D
PCT100 / 10D _
10.0
6
0.9
150.0
C
PCT150 / 10C _
15.0
8
0.9
150.0
D
PCT150 / 10D _
15.0
8
0.9
150.0
H
PCT150 / 10H _
15.0
8
0.9
220.0
C
PCT220 / 10C _
22.0
8
0.5
220.0
D
PCT220 / 10D _
22.0
8
0.5
220.0
H
PCT220 / 10H _
22.0
8
0.5
330.0
D
PCT330 / 10D _
33.0
8
0.9
330.0
H
PCT330 / 10H _
33.0
8
0.9
470.0
H
PCT470 / 10H _
47.0
10
0.5
16 V DC
@
85°C
(10 V DC
@
125°C)
1.0
A
PCT1
/ 16A _
0.5
4
11.0
1.5
A
PCT1.5 / 16A _
0.5
6
8.0
2.2
A
PCT2.2 / 16A _
0.5
6
6.5
3.3
A
PCT3.3 / 16A _
0.5
6
5.0
3.3
B
PCT3.3 / 16B _
0.5
6
4.5
4.7
A
PCT4.7 / 16A _
0.8
6
4.0
4.7
B
PCT4.7 / 16B _
0.8
6
3.5
6.8
A
PCT6.8 / 16A _
1.1
6
3.5
6.8
B
PCT6.8 / 16B _
1.1
6
2.5
6.8
C
PCT6.8 / 16C _
1.1
6
2.5
10.0
A
PCT10
/ 16A _
1.6
8
3.0
10.0
B
PCT10
/ 16B _
1.6
6
2.8
10.0
C
PCT10
/ 16C _
1.6
6
2.0
15.0
A
PCT15
/ 16A _
2.4
6
2.0
15.0
B
PCT15
/ 16B _
2.4
6
2.5
15.0
C
PCT15
/ 16C _
2.4
6
1.8
22.0
B
PCT22
/ 16B _
3.5
6
2.3
22.0
C
PCT22
/ 16C _
3.5
6
1.0
22.0
D
PCT22
/ 16D _
3.5
6
1.1
33.0
B
PCT33
/ 16B _
5.3
8
2.1
33.0
C
PCT33
/ 16C _
5.3
6
1.5
33.0
D
PCT33
/ 16D _
5.3
6
0.9
47.0
C
PCT47
/ 16C _
7.5
6
0.5
47.0
D
PCT47
/ 16D _
7.5
6
0.9
68.0
C
PCT68
/ 16C _
10.9
6
1.3
68.0
D
PCT68
/ 16D _
10.9
6
0.9
100.0
C
PCT100 / 16C _
16.0
8
1.0
100.0
D
PCT100 / 16D _
16.0
6
0.6
100.0
H
PCT100 / 16H _
16.0
6
0.9
150.0
D
PCT150 / 16D _
24.0
6
0.9
150.0
H
PCT150 / 16H _
24.0
8
0.3
220.0
H
PCT220 / 16H _
35.2
10
0.5
330.0
H
PCT330 / 16H _
52.8
30
0.4
Standard and Extended Range
Surface Mount Tantalum Capacitors
PCT
nemco
NEMCO reserves the right to supply a higher voltage rating, tighter tolerance and / or lower ESR in the same case size, to the same reliability standards.
_
Insert tolerance M (+20%) or K(+10%) to complete the Nemco part number
