Miniature Size
Surface Mount Tantalum Capacitors
MCT
27
FEATURES
0402 footprint - Nemco case size P
0603 footprint - Nemco case size R
Lead-free
RoHS compliant
Capacitance range: 0.47
μf to 22 μf
Voltage range: 2 to 16 WVDC
Operating temperature range -55°C to +125°C, 2/3 x Vr (linear derating) above +85°C
Meets or exceeds EIA 535 BAAC and IECQ standards (QC300801/US0001, IS - 28)
Surge tested for maximum robustness
Laser marking polarity stripe
Encapsulant material satisfies the UL 94 VO flammability classification
MSL (moisture sensitivity level) per IPC/Jedec J-STD-020B is level 1
Miniature
Surface Mount Tantalum Capacitors
nemco
Lead Free
Pb
RoHS
compliant
0603
footprint
case size
R
0402
footprint
case size
P
