18
6.3 V DC @ 85°C cont. (4 V DC @ 125°C)
470.0 H 200 LSR470 / 6H _ 200 28.0 10 908 817 363
470.0 Z 40 LSR470 / 6Z _ 40 28.0 10 2500 2250 1000
470.0 Z 55 LSR470 / 6Z _ 55 28.0 10 2132 1919 853
470.0 Z 100 LSR470 / 6Z _ 100 28.0 10 1581 1423 632
680.0 H 18 LSR680 / 6H _ 18 41.0 6 3873 3486 1549
680.0 H 23 LSR680 / 6H _ 23 41.0 6 3426 3084 1370
680.0 H 45 LSR680 / 6H _ 45 42.8 10 1915 1723 766
680.0 H 60 LSR680 / 6H _ 60 42.8 10 1658 1492 663
680.0 H 100 LSR680 / 6H _ 100 42.8 10 1285 1156 514
680.0 Z 23 LSR680 / 6Z _ 23 41.0 6 3520 3168 1408
680.0 Z 35 LSR680 / 6Z _ 35 42.8 14 2673 2405 1069
680.0 Z 40 LSR680 / 6Z _ 40 42.8 10 2500 2250 1000
680.0 Z 50 LSR680 / 6Z _ 50 42.8 10 2236 2012 894
1000.0 H 25 LSR1000/ 6H _ 25 63.0 8 3286 2958 1315
1000.0 H 100 LSR1000/ 6H _ 100 60.0 20 1285 1156 514
1000.0 Z 20 LSR1000/ 6Z _ 20 63.0 8 3775 3397 1510
1000.0 Z 40 LSR1000/ 6Z _ 40 60.0 16 2500 2250 1000
1000.0 Z 50 LSR1000/ 6Z _ 50 60.0 16 2236 2012 894
10 V DC @ 85°C (7 V DC @ 125°C)
2.2 A 1800 LSR2.2 / 10A _1800 0.5 6 204 184 82
4.7 A 1400 LSR4.7 / 10A _1400 0.5 6 231 208 93
6.8 A 1800 LSR6.8 / 10A _1800 0.7 6 204 184 82
10.0 A 900 LSR10 / 10A _ 900 1.0 6 289 260 115
10.0 A 1800 LSR10 / 10A _1800 1.0 6 204 184 82
15.0 A 1000 LSR15 / 10A _1000 1.5 6 274 246 110
15.0 B 450 LSR15 / 10B _ 450 1.5 6 435 391 174
15.0 B 600 LSR15 / 10B _ 600 1.5 6 376 339 151
22.0 A 900 LSR22 / 10A _ 900 2.2 8 289 260 115
22.0 B 400 LSR22 / 10B _ 400 2.2 6 461 415 184
22.0 B 500 LSR22 / 10B _ 500 2.2 6 412 371 165
22.0 B 700 LSR22 / 10B _ 700 2.2 6 348 314 139
22.0 C 300 LSR22 / 10C _ 300 2.2 6 606 545 242
33.0 A 700 LSR33 / 10A _ 700 3.3 8 327 295 131
33.0 B 250 LSR33 / 10B _ 250 3.3 6 583 525 233
33.0 B 425 LSR33 / 10B _ 425 3.3 6 447 402 179
33.0 B 500 LSR33 / 10B _ 500 3.3 6 412 371 165
33.0 B 650 LSR33 / 10B _ 650 3.3 6 362 325 145
33.0 C 150 LSR33 / 10C _ 150 3.3 6 856 771 343
33.0 C 375 LSR33 / 10C _ 375 3.3 6 542 487 217
33.0 C 500 LSR33 / 10C _ 500 3.3 6 469 422 188
47.0 B 250 LSR47 / 10B _ 250 4.7 8 583 525 233
47.0 B 350 LSR47 / 10B _ 350 4.7 8 493 444 197
47.0 B 500 LSR47 / 10B _ 500 4.7 8 412 371 165
47.0 B 650 LSR47 / 10B _ 650 4.7 8 362 325 145
47.0 C 200 LSR47 / 10C _ 200 4.7 6 742 667 297
47.0 C 350 LSR47 / 10C _ 350 4.7 6 561 505 224
47.0 D 100 LSR47 / 10D _ 100 4.7 6 1225 1102 490
68.0 B 600 LSR68 / 10B _ 600 6.8 8 376 339 151
68.0 C 80 LSR68 / 10C _ 80 6.8 6 1173 1055 469
68.0 C 100 LSR68 / 10C _ 100 6.8 6 1049 944 420
68.0 C 200 LSR68 / 10C _ 200 6.8 6 742 667 297
68.0 C 300 LSR68 / 10C _ 300 6.8 6 606 545 242
68.0 D 100 LSR68 / 10D _ 100 6.8 6 1225 1102 490
68.0 D 150 LSR68 / 10D _ 150 6.8 6 1000 900 400
100.0 B 400 LSR100 / 10B _ 400 10.0 8 461 415 184
100.0 C 75 LSR100 / 10C _ 75 10.0 8 1211 1090 484
100.0 C 100 LSR100 / 10C _ 100 10.0 8 1049 944 420
100.0 C 150 LSR100 / 10C _ 150 10.0 8 856 771 343
100.0 C 200 LSR100 / 10C _ 200 10.0 8 742 667 297
100.0 D 50 LSR100 / 10D _ 50 10.0 6 1732 1559 693
100.0 D 65 LSR100 / 10D _ 65 10.0 6 1519 1367 608
100.0 D 80 LSR100 / 10D _ 80 10.0 6 1369 1232 548
100.0 D 100 LSR100 / 10D _ 100 10.0 6 1225 1102 490
100.0 D 125 LSR100 / 10D _ 125 10.0 6 1095 986 438
100.0 D 150 LSR100 / 10D _ 150 10.0 6 1000 900 400
_ Insert tolerance M (+20%) or K(+10%) to complete the Nemco part number
NEMCO reserves the right to supply a higher voltage rating, tighter tolerance and / or lower ESR in the same case size, to the same reliability standards.
ESR tan
δ
Max. Ripple Current
Capacitance Case DCL
@ 100Khz max. @ 100kHz mA
μF
Size Nemco Part No. μA max.
max. m
Ω
(%)
(milliamps)
(microfarads) (milliohms) (microamps)
25°C 85°C 125°C
PART NUMBERS & SPECIFICATIONS
Low ESR
Surface Mount Tantalum Capacitors
LSR nemco
δ
μ μ
Ω
