PNEG-1616
1200 VISION X-STREAM PARTS MANUAL
Plenum Divider
7
8
9
10
9
Plenum divider clean-out door.
The photo above and on page 16 was taken before plenum end panels
where installed.
Plenum divider.
ITEM
NUMBER
PA RT NUMBER
DESCRIPTION
1214
1216
1218
1220
1222
1226
1A
D01-2466
COLUMN END PA NEL FRONT RIGHT
1
1
1
1
1
1
1B
D01-2467
COLUMN END PA NEL FRONT LEFT
1
1
1
1
1
1
2
D01-0113
WA LK RA IL MOUNTING BRA CKET
18
20
22
24
28
32
3
D01-0152
TOP EDGE A NGLE GUSSET - LH
14
16
18
20
22
26
3a
D01-0153
TOP EDGE A NGLE GUSSET - RH
2
2
2
2
2
2
4
D01-0127
SCREEN, ROOF SHEET
14
16
18
20
22
26
5
D31-0013
SCREEN, OUTSIDE WA LL SHEET
14
16
18
20
22
26
6
D01-0128
SCREEN, HOPPER SHEET
14
16
18
20
22
26
7
D31-0032
PLENUM DIV IDER: MF: BOTTOM
12
14
16
18
20
24
8
D31-0033
PLENUM DIV IDER: MF: BOTTOM END
2
2
2
2
2
2
9
D31-0260
CLEA N-OUT DOOR GUIDE
4
4
4
4
4
4
10
D31-0259
PLENUM DIV IDER CLEA N-OUT DOOR
2
2
2
2
2
2
11
D21- 0011-PP
FRA ME RA IL, 14' RIGHT
1
11
D01- 0538-PP
FRA ME RA IL, 16' RIGHT
1
11
D31- 0044-PP
FRA ME RA IL, 18' RIGHT
1
11
D61- 0002-PP
FRA ME RA IL, 20' RIGHT
1
11
D101-0002-PP FRA ME RA IL, 22' RIGHT
1
11
D71- 0001-PP
FRA ME RA IL, 26' RIGHT
1
12
D01-0005
SIDE LEG PORTA BLE DRY ER
10
12
14
16
16
20
13
D01-0004
GUSSET PLA TE
16
18
20
22
24
28
14
D01-0007
CORNER LEG PORTA BLE DRY ER
6
6
6
6
8
8
15
D01-0012
HITCH BRA CKET RIGHT
2
2
2
2
2
2
16
D01-0011
HITCH BRA CKET LEFT
2
2
2
2
2
2
17
D01-0008
FRONT & REA R FRA ME TIE CHA NNEL
4
4
4
4
6
6
18
D01-1374
BOTTOM A UGER BEA RING PLA TE
1
1
1
1
1
1
19
D01-0050P
CONNECTOR SHEET, PERFORA TED
14
16
18
20
22
26
20
D01-0045P
A CCESS DOOR, PERFORA TED
14
16
18
20
22
26
21
D01-0039
DOOR LA TCH
28
32
36
40
44
52
22
S-6552
PIN, HA IR CLIP 3/32"
28
32
36
40
44
52
23
DC-1229
DECA L, WA RNING METER ROLL ROT.
14
16
18
20
22
26
