10

PNEG-1616

1200 VISION X-STREAM PARTS MANUAL

22

22

23

23

23

23

24

Meter Roll

Bearing

See pg. 11

Items 16, 17, 18

Meter Roll

Bearing

See pg. 11

Items 16, 17, 18

Meter Roll

Bearing

See pg. 11

Items 16, 17, 18

Meter Rolls and Their Placement in the Dryer

22

Metering Rolls and their placement in the dryer.

NOTE: Item 22 at the rear of

dryer is a front section

meter roll that is used as a

rear section on 16 and 20

foot dryers only.

This end is the front (fan/heater) end of the dryer.
