5. Control Boxes
62 PNEG-1402 Vision Series Model 1100 Portable Dryers
Upper Control Box Component Part Numbers (Continued)
1112 Upper Control Box Component Parts List (See Figure 5F)
Ref #
1112 Part #
Description Circuit
220V 1 PH 208V 3 PH 220V 3 PH 440V 3Ph 575V 3Ph
1 D01-0480 D01-0480 D01-0480 D01-0480 D01-0480 Power Box Bock Panel N/A
2 D03-0475 D03-0473 D03-0473 D03-0471 D03-0471 Overload Load
3 D03-0482 D03-0479 D03-0477 D03-0474 D03-0473 Overload Load Aux.
4 D03-0473 D03-0473 D03-0472 D03-0471 D03-0543 Overload Unload
5 D03-0482 D03-0479 D03-0477 D03-0474 D03-0473 Overload Unload Aux.
6 D03-0490 D03-0489 D03-0488 D03-0488 D03-0488 Contactor Load
7 D03-0494 D03-0492 D03-0491 D03-0489 D03-0489 Contactor Load Aux.
8 D03-0488 D03-0488 D03-0488 D03-0488 D03-0488 Contactor Unload
9 D03-0494 D03-0492 D03-0491 D03-0489 D03-0489 Contactor Unload Aux.
10 D01-0531 D01-0531 D01-0531 D01-0531 D01-0531 Terminal - Block Entrelec 4 mm Control
11 D01-0532 D01-0532 D01-0532 D01-0532 D01-0532 Terminal - Blank End Protector Control
12 D01-0533 D01-0533 D01-0533 D01-0533 D01-0533 Terminal - Entrelec End Stop Control
13 D01-0534 D01-0534 D01-0534 D01-0534 D01-0534 Terminal - Entrelec Ground Block Control
14 HF-7203 HF-7203 HF-7203 HF-7203 HF-7203 Relay, 3 PDT 120V RH3B-U IDEC Control
15 07097555 070975553 07097555 07097555 07097555 Relay Base, 3 PDT Control
16 FH-3807 FH-3807 FH-3807 FH-3807 FH-3807 Transformer Control
17 006-1184-8 006-1184-8 006-1184-8 006-1184-8 006-1184-8 Terminal Ground Bar Ground
18 D03-0736-C D03-0736-C D03-0736-C D03-0736-C D03-0736-C Dryer I/O PCB Assembly Computer Vision Control
19 D03-0106 D03-0106 D03-0106 D03-0106 D03-0106 SCR Contactor 15 Amp 3 Pole Meter Roll
20 D03-0660-34 D03-0660-34 D03-0660-34 D03-0660-34 D03-0660-34 Breaker, 3 Amp 3 Pole Delayed Meter Roll
21 D03-0661 D03-0661 D03-0661 D03-0661 D03-0661 Breaker 6 Amp 1 Pole 110 VAC Control
22 D03-0104-3/4 D03-0104-3/4 D03-0104-3/4 D03-0104-3/4 D03-0104-3/4 SCR Drive Board Assembly 3/4 HP DC Meter Roll
23 D01-0550 D01-0550 D01-0550 D01-0550 D01-0550 Power Box Catch Angle, Bottom N/A
24 D01-0491 D01-0450 D01-0498 D01-0613 D03-0533 Main Breaker Power
25 D33-0001 D33-0001 D33-0001 D33-0001 D33-0001 SCR Resistor Plug-In 3/4 HP 180V Meter Roll
26 D03-0464 D03-0459 D03-0457 D03-0528 D03-0531 Breaker Unload Aux.
27 D03-0300 D03-0293 D03-0293 D35-0001 D35-0001 Distribution Block Power
28 D03-0448 D03-0380 D03-0380 D03-0389 D03-0531 Breaker Unload
29 D03-0464 D03-0459 D03-0457 D03-0528 D03-0531 Breaker Load Aux.
30 D03-0508 D03-0380 D03-0380 D03-0389 D03-0531 Breaker Load
31 D03-0466 D03-0468 D03-0465 D03-0529 D03-0532 Breaker Fan
32 D01-0551 D01-0551 D01-0551 D01-0551 D01-0551 Power Box Catch Angle, Top N/A
