3. Fan/Heaters
PNEG-1402 Vision Series Model 1100 Portable Dryers
39
Flame Probe, Ignitor and Burner Assemblies Parts List
Ref #
Part #
Description
36'' F/H
40'' F/H
42'' F/H
1-3
TF-1559-N
Flame Probe Assembly Network
1
1
1
1
HH-7025
Boot 8 mm Silicone 90°
1/Assembly
2
THH-4179
Flame Sensor 6" Long Rod
1/Assembly
3
CD-0187
Flame Sensor Bracket
1/Assembly
4-8
TF-1558
Ignitor Assembly
1
1
1
4
HF-7204
Dual Probe Ignitor Bracket
1/Assembly
5
D01-0878
Ignitor Air Deflector Angle
1/Assembly
6
HF-7201
Ignitor Half Clamp
2/Assembly
7
CD-0238
Ignitor Flame
2/Assembly
8
TF-1876
Ignition Wire Assembly (Includes Both Wires)
1/Assembly
9
HH-7056
Cone 36/42" Burner S.S.
1
1
1
10
11
THH-4064
Unilet Type LRL Conduit Box 1/2"
1
1
1
12
027-1006-9
Thermostat - High-Limit 200°F AUT
1
1
1
13
D01-1473
Housing High-Limit Plate
1
1
1
14
No Number
Lid for LRL Conduit Box is Part of Ref #11
Not Applicable
15
TFC-0076
Neoprene Gasket, Conduit Body
1
1
1
16-20
BA-36
36" Burner Assembly
1
16
THF-3038
Diverter Bracket 36" and 40"
3/Assembly
17
THF-3038P
Diverter Bracket 36" and 40" Perfed
4/Assembly
18
THF-3039
Diverter Bracket 36" and 40" w/ Hole
1/Assembly
19
THF-3057
Flame Spreader 36-42"
1/Assembly
20
CD-0091
Burner Weldment CD 36" and 40"
1/Assembly
21-24
BA-40-2
40" Burner Assembly
1
21
CD-0448P
Diverter Bracket 42" Perfed
4/Assembly
22
CD-0448
Diverter Bracket 42"
4/Assembly
23
CD-0208
Burner Weldment CD 42"
1/Assembly
24
THF-3057
Flame Spreader 36-42"
1/Assembly
21-24
BA-42
42" Burner Assembly
1
21
CD-0448P
Diverter Bracket 42" Perfed
4/Assembly
22
CD-0448
Diverter Bracket 42"
4/Assembly
23
CD-0208
Burner Weldment CD 42"
1/Assembly
24
THF-3057
Flame Spreader 36"-42"
1/Assembly
