Metering roll drive (continued), Auger and meter roll drive trains – Grain Systems PNEG-1402 User Manual
Page 32
2. Auger and Meter Roll Drive Trains
32
PNEG-1402 Vision Series Model 1100 Portable Dryers
Metering Roll Drive (Continued)
Figure 2F
Metering Roll Drive Parts List
and
Ref #
Part #
Description
Qty
1108T
1112
1114
1116
1118
1120
1122
1126
1
D01-0007
Corner Leg Portable Dryer
4
6
6
6
6
6
8
8
2
D11-0004
Frame Rail, 8' Left
1
2
D51-0001
Frame Rail, 12' Left
1
2
D21-0010
Frame Rail, 14' Left
1
2
D01-0537
Frame Rail, 16' Left
1
2
D31-0043
Frame Rail, 18' Left
1
2
D61-0001
Frame Rail, 20' Left
1
2
D101-0001
Frame Rail, 22' Left
1
2
D71-0002
Frame Rail, 26' Left
1
3
D01-0016
Motor Mount Support Bracket
1
1
1
1
1
1
1
1
4
D01-0081
Motor Mount
1
1
1
1
1
1
1
1
5
D01-0704
SCR Motor Gear Box Mount
1
1
1
1
1
1
1
1
6
D01-0008
Front and Rear Frame Tie Channel
2
4
4
4
4
4
6
6
7
D03-0232
Motor 3/4 HP DC w/ Gear Box 50:1
1
1
1
1
1
1
1
1
8
D01-2435
Front Bearing Plate 2008 4" Meter Rolls
1
1
1
1
1
1
1
1
9
D02-0029
Sprocket 40H30
2
2
2
2
2
2
2
2
10
D31-0316
Front Bottom Auger Shaft
1
1
1
1
1
1
1
1
11
D32-0001
Flangette Bearing 1-1/2"
2
2
2
2
2
2
2
2
12
D01-0196
Sprocket Idler Assembly
2
2
2
2
2
2
2
2
13
D03-0257
Sprocket 4015 x 7/8" Bore w/ Keyway
1
1
1
1
1
1
1
1
14
S-9168
Key Square 1/4" x 1"
3
3
3
3
3
3
3
3
15
S-6290
Chain #40 Roller Chain
6'
6'
6'
6'
6'
6'
6'
6'
16
D02-0031
#40 Chain Connecting Link
1
1
1
1
1
1
1
1
17
DC-972
Decal, Chain Warning
2
2
2
2
2
2
2
2
18
D01-0003
Adaptor Plate
4
4
4
4
4
4
4
4
19
GK1583
Flangette Bearing 1", w/ Lock Collar
4
4
4
4
4
4
4
4
20
D01-0006
Meter Roll Drive Shaft (Front)
2
2
2
2
2
2
2
2
21
D01-0272
Meter Roll Shaft Stub (Rear)
2
2
2
2
2
2
2
2
Front meter roll bearing
Rear meter roll bearing
18
18
19
21
19
20
