Page 20: Figure 1q, Front and rear ladder assembly

background image

1. Main Structure Assembly

20

PNEG-1402 Vision Series Model 1100 Portable Dryers

Ladder and Fan Assemblies

Figure 1Q

Ladder and Fan Assembly Parts List

Ref #

Part #

Description

Qty

1108T

1112

1114

1116

1118

1120

1122

1126

1-4

D31-0293

Ladder Assembly, Tall Profile

1

1

2

2

2

2

2

2

1

D01-1012

Ladder Bracket

4/Assembly

2

D31-0020

Ladder Rail

2/Assembly

3

D01-0112

Ladder Rung

10/Assembly

4

D01-0114

Ladder Lower Bracket

1/Assembly

5

CD-0544

Grill Guard: 36"

1

1

5

CD-0547

Grill Guard: 40" and 42"

1

1

1

1

1

1

6

CD-0543-Y

Venturi: 36" Ochre

1

1

6

CD-0545-Y

Venturi: 40" Ochre

1

1

6

CD-0546-Y

Venturi: 42" Ochre

1

1

1

1

7

D51-0007

Front Fan Support 1-36"

1

1

7

D01-1458

Front Fan Support 1-40"

1

1

7

D51-0132

Front Fan Support 1-42"

1

1

1

1

Front and rear ladder assembly

1

2

3

1

4

1

2

1

3

3

5

6

7
