Table 1 Banks EconoMind Fault Codes
Code Event Course of Action
1,1
Fuel Rail Pressure (FRP)
Input Voltage Out of Range.
Turn ignition OFF and check 3-pin FRP sensor connections. Turn ignition back
ON and re-check for presence of code.
1,2
Manifold Absolute Pressure
(MAP) Input Voltage Out of
Range.
Turn ignition OFF and check 4-pin MAP sensor connections. Turn ignition back
ON and re-check for presence of code.
1,3
Power Level Selector Switch
Input Value Out of Range.
Turn ignition OFF and make sure either Banks PowerPDA or Power Level
Selector Switch is connected to EconoMind tuner. If Power Level Selector
Switch is connected (no Banks PowerPDA), check 2-pin connection on tuner’s
in-cab cable. Turn ignition back ON and re-check for presence of code.
1,4
ScI communications Error
With Vehicle.
Turn ignition OFF and check in-cab OBD II and 8-pin cable connections. Turn
ignition back ON and re-check for presence of code.
2,1
Fuel Rail Pressure (FRP)
Output Voltage Out of Range.
Turn ignition OFF and check 3-pin FRP sensor connections. Turn ignition back
ON and re-check for presence of code.
2,2
Manifold Absolute Pressure
(MAP) Output Voltage Out of
Range.
Turn ignition OFF and check 4-pin MAP sensor connections. Turn ignition back
ON and re-check for presence of code.
2,3
Exhaust Gas Temperature
(EGT) Sensor Open circuit or
Out of Range.
Turn ignition OFF and check thermocouple ring-terminal connections (2). Turn
ignition back ON and re-check for presence of code.
2,4
J1850 communications Error
With Vehicle.
Turn ignition OFF and check in-cab OBD II and 8-pin cable connections. Turn
ignition back ON and re-check for presence of code.
3,1
crankshaft Position (cKP)
Signal Fault or Intermittent
Power.
Turn ignition OFF and check 3-pin cKP and cMP sensor connections and fuse-
tap power connection to EconoMind tuner (in engine compartment fuse box).
Start engine and re-check for presence of code.
3,2 Internal Module Malfunction. Turn ignition OFF and check all EconoMind tuner connections. Turn ignition back
ON and re-check for presence of code.
3,3
Low Battery Voltage or
Internal Module Malfunction..
Turn ignition OFF and check fuse-tap power connection to EconoMind tuner (in
engine compartment fuse box). Turn ignition back On and re-check for presence
of code.
4,2
Transmission Slippage
Detected.
Transmission is slipping excessively. Code will automatically clear once
transmission stops slipping (repaired).
4,3
Unlearned Transmission Type
and Gear Ratios.
Perform Transmission Learning procedure in Section 6. code will automatically
clear once transmission type and gear ratios (auto trans. only) have been
learned successfully.
4,4
Engine Rating changed or
Not Learned.
Turn ignition On and allow EconoMind to learn engine rating (approx. 10
seconds). If EconoMind has been moved to a different truck and engine
platform, perform “throttle pedal CLEAR” routine and allow EconoMind to
re-learn engine rating.
If problem persists, call Gale Banks Engineering Tech Support.
34
96812 v.7.0
