51124 pg 2
Rev. B 0204
Removing the Old Top
Parts List
Fabric Top Qty - 1
Quarter Window, Right Qty - 1
Quarter Window, Left Qty - 1
Rear Window Qty - 1
Door Cover, Right Qty - 1
Door Cover, Left Qty - 1
Pull down and then out to
release the fabric from the
retainer
Step Three
Release the rear corners of the top. Pull gently
down and then out to release the plastic strip from
the retainer on the vehicle.
Step Two
Release the latch that secures the header to
the windshield. Pull up on the lever and then
down and out to release the hook from the
slot in the windshield frame.
Windshield
Frame
Windshield
Header Latch
Pull lever up
Release hook
from slot
Unsnap the fabric
from the rear bow
Step Four
Unsnap the fabric from the rear bow and
allow the bow to drop onto the tailgate.
Tools Needed
Shoe Horn
Safety Glasses
Razor Knife
Phillips Screwdriver
Release Plastic Strips
from Retainers
Step One
Remove the Quarter Windows and the Rear Window. Remove the
metal Tailgate Bar from the bottom of the Rear Window and set it
aside.
Release the plastic strip sewn to the top above the doors. Pull down
and out to slip the plastic out of the channel.
Caution
Safety glasses should be worn at all
times while installing this product.
