Rev. H 0113 56820 pg. 5
Trektop NX Installation Instructions
Loosen the speaker pod. Slip the straps between
the speaker pod and the sport bar. Wrap the straps
around the sport bar on each side of the vehicle.
Thread the ends of the straps through the buckles
and tighten. Tighten the speaker pod.
Secure Straps to Sport Bar
Thread a J-Hook Buckle Strap through the buckle on one of the rear straps.
Hook the strap to the ledge inside the rear corner of the vehicle. Repeat on
both sides of the vehicle.
Secure Rear Straps
J-Hook
Buckle Strap
J-Hook
Buckle Strap
Orient the Rear Window with the plastic J-slide
toward the top. Align the J-slide with the J-slide
sewn into the rear of the Top. Slide them together
until the Rear Window is centered in the opening
and you feel or hear the J-slides snap together.
Install Rear Window
Rear Window
J-Slide
Open the Sun Rider to make it easier to install the Quarter Windows and the
Rear Window.
Open Sun Rider
