RF Level -80 to -20 dBm, ±3 dB
MER 10 to 32 dB, ±2 dB
Constellation Diagram dependent on selected modulation
MSA-OPT-DVBS-S2
Input Ports Limit 4 (2 slots x 2 ports per slot )
Antenna Inputs 2 F-type, female, 75 ohms
Number of Channels 1 (16/32-APSK)
2 (QPSK/8-PSK)
Monitoring Outputs 2x ASI
Tuning Range 950 to 2150 MHz
Input Return Loss >10 dB
Input Sensitivity -60 to -30 dBm
Baud Rate 2 to 40 MBd
Metrology RF Level -60 to -30 dBm
SNR 5 to 35 dB
MER 10 to 26 dB
BER (DVB-S2) Pre LDPC
Constellation 256x256
LNB Supply (per channel) 13/18 V 400 mA
ORDERING INFORMATION
MSA-100-MPEG2 Multi-source analyzer, entry-level platform, MPEG-2 format, standard with 1 codec
and 4 SD or 2 HD PIPs, providing full conformance testing and traffic status
monitoring
MSA-100-MPEG4 Multi-source analyzer, entry-level platform, MPEG-4 format, standard with 1 codec
and 4 SD or 2 HD PIPs, providing full conformance testing and traffic status
monitoring
MSA-100-H264 Multi-source analyzer, entry-level platform, H.264 format, standard with 1 codec
and 4 SD or 2 HD PIPs, providing full conformance testing and traffic status
monitoring
MSA-100-VC1 Multi-source analyzer, entry-level platform, VC-1 format, standard with 1 codec
and 4 SD or 2 HD PIPs, providing full conformance testing and traffic status
monitoring
Note: Number of PIPs and/or shadow testing varies depending on codec type, picture resolution and bitrate.
