MSA-100 Multi-Source Analyzer
969 Horsham Road l Horsham, Pennsylvania 19044 USA l Phone: 215-675-2053 Fax: 215-675-7543 l [email protected]
Streaming Protocols
Signaling RTSP (RFC 2326), SDP (RFC 2327)
Transport RTP (RFC 3550, RFC 3551)
Video Payload MP4V-ES (RFC 3016): SP and ASP profiles
H264 (RFC 3984): baseline, extended, main and high profiles
Audio Payload MP4A-LATM (RFC 3016): AAC and HE-AAC
MPEG-4 generic (RFC 3640): AAC-lbr and AAC-hbr
Note: Payload interleaving mode is not currently supported
RTMP (Real-Time Messaging Protocol 1.0)
Transport RTMP/TCP
Video Payload H.264/AVC: baseline, extended, main and high profiles
Audio Payload AAC, HE-AAC v1, HE-AAC v2, MPEG audio
Apple HTTP Live (IETF Internet Draft HTTP Live Streaming)
Transport TS/TCP
Video Payload H.264/AVC: baseline, extended, main and high profiles
Audio Payload AAC, HE-AAC v1, HE-AAC v2
Video Compression Formats
MPEG-1 Video (ISO/IEC 11172-2)
MPEG-2 Video
(ISO/IEC 13818-2) Supported profiles (all levels):
- Simple
- Main
- 4:2:2
Note: HD is supported by main profile @ high level
MPEG-4 Part 2 Video (ISO/IEC
14496-2) Supported profiles:
- Short video header
- Simple (L0 – L5)
- Advanced simple (L0 – L5)
Supported object type:
- Rectangular
H.264/AVC Video
(ITU-T H.264) Supported profiles (all levels)
- Baseline
- Main
- Extended
- High
SMPTE VC-1 Video
(SMPTE 421M) Supported profiles (all levels)
- Simple
- Main
- Advanced
Video Layer Analysis Video stream information
Video picture graph and bitrate profile
Video conformance tests from sequence level down to block level
