Operating Environment
Operating Temperature Range 50° to 95° F (10 to 35° C)
Non-Operating Temperature Range -40° to 158° F (-40 to 70° C)
Humidity Range 8 to 90% non-condensing
Non-Operating Humidity Range 5 to 95% non-condensing
Standard Inputs 2x RJ45, 10/100/1000 full line rate @ standard MTU size IP traffic
OPTIONAL INPUTS
Note: MSA-100 has a total of 2 slots available for input options which support 1 DVB-ASI module and 1 RF input
options or 2 RF input modules (MSA-OPT-DVB-T or MSA-OPT-DVBS-S2).
MSA-OPT-DVB-ASI
Input Ports Limit 4 (1 slot x 4 ports )
ASI/SDI Connector 4x BNC, 75 ohms
Input Return Loss >15 dB
Hardware Buffering 32 MB/channel
ASI Physical Layer DVB-ASI (coaxial)
EN50083-9
Rx Bitrate 0 to 214 Mb/s
Resolution <1 bit/s
Packet Size 188 or 204 bytes
MSA-OPT-DVB-T
Input Ports Limit 4 (2 slots x 2 ports per slot)
Antenna Inputs 2 F-type, female, 75 ohms
Antenna Power 2x 5 V @ 30 mA
Tuning Range 50 to 860 MHz
Bandwidth 6/7/8 MHz
Input Sensitivity -78 to -20 dBm
Metrology RF Level -80 to -20 dBm, ±3 dB
MER/SNR 10 to 32 dB, ±2 dB
BER Pre- and Post-Viterbi
Constellation 1023x1023
MSA-OPT-DVB-T2
Input Ports Limit 2 (2 slots x 1 ports per slot)
Antenna Inputs F-type, female, 75 ohms
Tuning Range 50 to 860 MHz
Bandwidth 6/7/8 MHz
Input Sensitivity -78 to -20 dBm
