Msa-100 multi-source analyzer – Toner Cable MSA-100 Multi-Source Analyzer User Manual
Page 7
969 Horsham Road
l
Horsham, Pennsylvania 19044 USA
l
Phone: 215-675-2053 Fax: 215-675-7543
l
Specifications Subject To Change Without Notice
Rev 11-12
©Toner Cable Equipment, Inc.
MSA-100 Multi-Source Analyzer
CAT error
Third Priority
NIT actual error
NIT other error
Unreferenced PID
SDT actual error
SDT other error
EIT actual error
EIT other error
EIT PF error
RST error
TDT error
Table Analysis
TS PSI
TS DVB-SI
TS ATSC-PSIP
RTSP SDP
Audio Layer Analysis
Audio Stream Information
Audio type
Audio bitrate
Sampling frequency
Channel mode
Other compression-format-dependent information
Audio Wave Monitor
Short-term wave window: 1 audio frame
Long-term wave window: 5 seconds
Fast PPM with digital clipping indicator
PPM Parameters
0 ms attack
12 dB/sec decay (fallback)
4 sec hold for peak
Audio Level Test
Silence detection
Max level detection
Digital clipping detection
Physical Characteristics
Dimensions (H x W x D)
1.75 x 19 x 25 in. (4.4 x 48.3 x 63.6 cm)
Weight
22.5 lbs (10.25 kg)
Power
Power Supply
Single supply
Voltage
110 to 240 VAC
Max Current
4.5 to 2.5 A
Frequency
60 to 50 Hz
Total DC Output
650 W
