Type LC
Average Output Power (minimum) -9 dBm
Average Output Power (maximum) -3 dBm
Mean Optical Wavelength 1270 to 1355 nm; 10 km range
Input Power (minimum) -20 dBm
Input Power (maximum) -3 dBm
Laser Mode Single-mode, 1310 nm FP laser
Supply voltage 3.135 to 3.465 V
Ejector Bail actuator operating case
Temperature -40º to 185º F (-40º to 85º C)
Gigabit Optical Multi-Mode (OP+SFP1+TRM) Laser
Output Power (minimum) -9.5 dBm
Output Power (maximum) -2 dBm
Output Center Wavelength 830 to 860 nm; 850 nm (typical)
Input Power (minimum) -17 dBm
Input Power (maximum) 0 dBm
Optical Input Wavelength 770 to 860 nm
Line Rate 1.25/1.0625 Gbaud
Laser Mode Multi-mode, 850 nm VCSEL
Voltage 3.3 V
Ejector Bail actuator operating case
Operating Case Temperature 23° to 176° F (-5° to 80°C)
Applicable Standards IEEE 802.3z 1000 Base SX specification for optical links
GPI In/Out
Connector 2 x 3 position screw terminal (Keystone 8739)
Input Signal Level +5 V
Output Signal Level ±75 V with reference to GPI out common
Physical Characteristics
Form Factor 3RU
Dimensions (H x W x D) 5.25 x 19 x 20.8 in. (13.3 x 48.3 x 52.8 cm)
(Depth includes 0.7 in (1.8 cm) of optional SFP module and transceiver)
Power Consumption No modules installed 90 W maximum
14 modules installed 650 W maximum
SFP
Gigabit Optical Single-Mode (OP+SFP+SEL) Laser
