6HOHQLRŒ0HGLD&RQYHUJHQFH3ODWIRUP
• Two genlock reference looping inputs utilizing standard BNC connectors
• Built-in, browser-based management system (no software required) that incorporates support for rich
interactive features through Microsoft® Silverlight®
• A General Purpose Interface (GPI) — Two GPI inputs and outputs are provided on a multi-pin type
connector
• Power Supply — Each frame includes one energy-efficient, 80 Plus Gold-certified power supply that
will power a fully loaded frame
Selenio options include a second power supply and a second controller for redundancy, as well as a
local control panel.
N+1 Redundancy
N+1 redundancy is supported in the Selenio frame. Redundancy is accomplished by using an external
router or a crosspoint on the Selenio controller module.
Redundancy is implemented through software provisioning (controller module, application module and
control system).
Without Selenio: Complex broadcast infrastructure and workflow
With Selenio: Significantly streamlined infrastructure and workflow
PRODUCT DETAILS
Every shipment of the Selenio frame includes the following:
• A controller for interface to control networks (with an option for data networks)
