6HOHQLRŒ0HGLD&RQYHUJHQFH3ODWIRUP
Input Voltage Rated 100 to 240 VAC
Operating 90 to 250 VAC
Frequency Rated 50 to 60 Hz
Operating 47 to 63 Hz
Input Current Rated 9A RMS maximum
Operating 8A RMS maximum at 90 VAC with 650 W output
3A RMS maximum at 250 VAC with 650 W output
Inrush Current 40A peak maximum @ high line, hot or cold start, duration not to exceed 10 ms
Efficiency The PSU will deliver an efficiency of no less than 86% at any net power level
greater than 25% of rated output
Power Factor >0.95 at output power >50% load @ 250 VAC input
>0.95 at output power >30% load @ 90 VAC input
>0.97 at 90 to 135 VAC and >0.95 at 180 to 250 VAC, typical
Harmonic Distortion Complies with the requirements of EN61000-3-2
External Reference - Genlock
Connector BNC (IEC169-8)
Impedance 75 ohms
Return Loss >40 dB 25 Hz to 10 MHz (SMPTE 318M-1999)
Common Mode Range 5.5 V pk-pk
CMRR 60 dB @ 60 Hz, 5 V pk-pk
Input Level NTSC/PAL-B: 1 V pk-pk, –6.0 dB to +6.0 dB
Tri-level sync: ±300 mV, –6.0 dB to +6.0 dB
DARS: 1 V pk-pk
Controller Module Reference
Standards 525i/59.94, 625i/50, 720p/25, 720p/29.97, 720p/30, 720p/50, 720p/59.94, 720p/60,
1080i/50, 1080i/59.94, 1080i/60, 1080sF/23.98, 1080sF/24, 1080sF/25,
1080sF/29.97, 1080sF/30, 1080p/23.98, 1080p/24, 1080p/25, 1080p/29.97,
1080p/30
Standard SMPTE 170M (NTSC), ITU-R BT.470-6 (PAL-B), SMPTE 274M (1080i, 1080p),
SMPTE 296M (720p), AES3 SMPTE 276M
Ethernet
Connector RJ-45
Standard 10/100/1000Base-T (10/100Base-T on front Ethernet port)
Differential Output Voltage 0.75 V ±0.83 dB
High Frequency Jitter 0.3 ns
CMRR 1V RMS 1 to 250 MHz
Clock Frequency 125 MHz ±0.01%
Power Supply
SPECIFICATIONS
