PROGRAMMING SUMMARY CHART
LOCATION FUNCTION
ENTRY LIMITS & CODE
OPTIONS CODE ENTRY FACTORY
DEFAULT
0 1 Master Code 4-8 Digits
01
MASTER CODE
#
NIL
0 2 Super User PIN 4-8 Digits
02
SUPER USER PIN
#
NIL
0 3 Common User PIN for O/P 1 4-8 Digits 03 COMMON USER PIN 1 # NIL
1 0 User PINs / Cards for O/P 1
CODE 1 - MEDIA:
1---EM Card
2---Private User PIN
3---EM Card+Sec User PIN
4---EM Card+Com User PIN
5---Deletion of User PIN
CODE 2 - USER ID:
000-999---Group 1
CODE 3 - USER PINs / Cards:
4-8 Digits / Cards
10
CODE1 CODE2 CODE3
#
NIL
4 0 Visitor Codes
CODE 1 - VISITOR ID: 01-50
CODE 2 - VALID PERIOD:
00---One Time
01-99 Hours
CODE 3 - VISITOR CODE:
4-8 Digits
40
CODE1 CODE2 CODE3
#
NIL
5 1 O/P Mode for O/P 1
OUTPUT MODE & TIME:
0--- Start / Stop
1---99999 Seconds,
Momentary
51
O/P MODE & TIME
#
5 Seconds
6 0 Personal Safety & Lock-out
LOCK-OUT CODE:
1---10 Trial, Lock-out 60 Sec.
5-10---5-10 Trial, Lock-Out 15
Minutes
00---No Lock-out
60
LOCK-OUT CODE
#
Code = 1,
10 Trials,
Lock-out 60
Seconds
7 0 PIN Entry Mode
ENTRY MODE:
1---Auto Mode
2---Manual Mode
70
ENTRY MODE
#
Mode = 2,
Manual Mode
7 1 Pacifier Tone ON-OFF
FUNCTION MODE:
0---OFF
1---ON
71
FUNCTION MODE
#
Mode = 1,
Pacifier Tone
ON
7 2 Output Announcer
72
FUNCTION MODE
#
Mode = 1
Announcer ON
7 3 Standby LED Flashing
73
FUNCTION MODE
#
Mode = 1,
Flashing On
9 0 Egress Delay Warning
CODE 1 - FUNCTION MODE:
1---Momentary, No warning
2---Momentary, with warning
4---Hold Contact, No warning
5---Hold Contact, with warning
CODE 2 - DELAY TIME:
0---No Delay
1-99 Seconds
90 CODE 1 CODE 2 #
Mode = 1
Momentary,
No warning
TIME = 0
No Delay
