CONFIGURATION OF THE OUTPUT MODES OF OUTPUT 1 (Location 51)
The relay output of this keypad is programmable for Start/Stop or Timing modes. Apart from the door access control,
alarm arm-disarm control, it is also an universal timer for automatic operator in industry with its 99,999 seconds (over
24 hours) programmable timer.
OUTPUT LOCATION
51
-- Location for Output 1
OUTPUT MODE & TIMING
0
– Start /Stop Mode (Toggle)
The number 0 sets the output to the Start / Stop mode. The output Starts when an User PIN and/or Card is entered/
read; the output Stops when an User PIN and/or Card is entered/read again.
1
-
99999
Seconds Momentary --- (Default -- Momentary 5 Seconds)
The output can be set in Momentary Mode with the time of 1 second to 99,999 seconds. The output will reset
automatically when the time expires OR it can be RESET manually at anytime with the Super User Code before the
end of the time.
Example : Reset Output 1 --
# 1
------------- Output 1 resets
PERSONAL SAFETY AND SYSTEM LOCK-OUT (Location 60)
SAFETY & LOCK-OUT OPTIONS
The Options are represented by their Mode Numbers in programming. They are described below:
1
--- After 10 successive false Card/User Code trials, the keypad locks during 60 seconds. -- (Default)
5
-
10
--- Selection of after 5 to 10 successive Card/User Code trials, the keypad locks during 15 minutes.
The keypad can be reset to release the lock-out with the “Super User Code” in the following way.
Example : Release the lock-out --
# 9
00
--- Disappearance of all the above lock-out securities.
SUPER USER CODE
1 to 2 Digits
LOCK-OUT MODES VALIDATION LOCATION
60 #
SUPER USER CODE
OUTPUT MODE & TIME VALIDATION LOCATION
51 0
or
1
-
99999 #
20
