OPERATION AND FUNCTIONS OF THE SUPER USER PIN

1) Operate Output 1 (Output Relay 1)

The operation of the Super User PIN is just like a normal User PIN. Simply key-in the PIN with a specific output
number for the Output. The Super User PIN can also be used to reset an operating output timer instantly.

---------- Output 1 Activates or Resets

2) Inhibit The User PINs For Output 1

The Super User PIN can also be used to inhibit the normal User PINs/Cards for the Output 1 (usually they are for
door strike). It enhances the security level of the access control system, such as to stop a keypad after office hour
or while the house is nobody inside. Once the Output 1 is inhibited, the User PINs/Cards for it become invalid and
those people even know the User PINs are refused during the system is inhibited. The inhibit function is toggled in
Start / Stop mode with the following code entry.

---------- The Whole Group of User PINs & Cards for Output 1 are Disabled

or Enabled in Toggle

NOTE:

The inhibit function setting with the Super User PIN applies to the whole group of User PINs and Cards for
Output 1.
For safety reason, the inhibit function initiated with the Super User PIN does not govern the Egress Button. The
door still can be opened with it from inside.
The function of the Super User PIN is not affected in the Inhibited Mode or Lock-out Mode. It is always a normal
user code for Output 1.

RECORD THE COMMON USER PINS FOR OUTPUT 1 (Location 03)

The Common User PIN is prepared for operating of the Output 1 as an enhance code. The Common User PINs MUST
work in the form of “Card + Common PIN” to operate the outputs to increase the security of the access control
system. See Location 10 for more information.
NOTE : Common User PIN alone can NOT be used to operate Output 1 directly.

COMMON USER PIN LOCATION

-- Location Stores The Common User PIN for Output 1

COMMON USER PINS

The Common User PIN can be 4 to 8 digits. Press # key to confirm the code entry.
When a new Common User PIN is keyed in and confirmed, the old one is replaced.
Example: Set a Common User PIN with the number of “1 3 5 7” for Output 1 ----
To deleted a Common User PIN from memory: Key in just the Location number and #. ----

4 to 8 Digits

SUPER USER PIN

COMMON USER PIN

VALIDATION

LOCATION

1357
