RECORD-DELETE PINS OR CARDS FOR OUTPUT 1 (Location 10)
Total of 1,000 User PINs and/or Cards are available for controlling of the output relay 1.
The Private User PINs and Cards MUST be unique. Repeated PINs will be rejected. Secondary User PINs in the “EM
Card + Secondary User PIN” can be repeated. See the Important Note --- Programming Criteria for Codes in page 13
for more information.
USER GROUP LOCATION
– Group 1 --For User PINs/Cards Controlling Output 1
1,000 Users are allowed in group 1 for O/P 1
SELECTION OF OPERATION MEDIA
Number 1, 2, 3 or 4 represents the Media to be used to operate the keypad.
Number 5 is the authorization code for deleting of an PIN and/or Card from
its User ID.
= EM Card only;
= Private User PIN only;
= EM Card + Secondary User PIN
= EM Card + Common User PIN
= Delete an User PIN &/or Card from the selected User ID number
= Clear all the PINs & Cards from the selected Location. It takes
few seconds to a minute to complete depending on the Location
selected and the data stored.Please see the programming example
below for the details.
USER ID NUMBER
A 3-digit ID is an identified number for each User PIN and/or Card.
Repeated ID number will be rejected by the system
ID Number
000
-
999
for 1,000 User PINs/Cards to operate Output 1
CARD &/OR USER PINS
The User PINs can be 4-8 digits. Key in the User PIN on each ID Number box, then confirm it with # key
Just simply put the EM card close to the reader window to read it on each ID Number box, then, confirm it with
# key if it is a Card ONLY, or Card + Common User PIN entry. The Common User PIN is NOT required to key-in
here. It will go into its location automatically after the Card is read.
Read the Card first, then key in the Secondary User PIN on each ID Number box, then confirm it with # key if it
is Card + Secondary User PIN. The Secondary User PINs can be duplicated or a proprietary User PIN but can
not be a duplicate of a Prime Code. Owner can use the same secondary User PIN for a group of Cards as a group
Common User Code (or called Department Code) for a specific relay output.
Cards (Operation Media # 1, 3, & 4) and Private User PINs (Operation Media 2) MUST be unique. A repeated EM
card or Private User PIN will be rejected and one long beep will be generated by the system to notify the owner.
10
1
-
5 000
-
999 #
10
1
2
3
4
5
0999
CARD &/OR USER PIN
VALIDATION
LOCATION
MEDIA
USER ID
CARD &/OR USER PIN
16
