6) Record an “EM Card + Commom User Code” to Operate The Output 1 for Door Open

004 #

(a) (b) (c) (d) (e)
(a) 10 = Programming Location for Output 1
(b) 4 = Programming option for EM Card + Common User Code
(c) 004 = One of the 1,000 User IDs for the User PIN/Card from 000-999
(d) Read Card = Put the Card close to the card reader
(e) # = Confirm the card is read, 2 beeps, the Common User Code goes to this User ID automatically
(f) A Common User Code (for example: 8 6 2 5) MUST be set at the Programming Location 03 first for this operation

mode. The code can be used for all the EM Cards in this operation mode.

REMARK:

If more User PINs and Cards are required for Output 1, repeat the procedures (3) , (4) , (5) or (6) above with other User
IDs, such as 005, 006, 007 --- 999 etc. Total 1,000 users are allowed. See Programming Location 10 for the details.

7) Close The Programming Mode

---- 2 beeps

The programming mode is closed. The keypad is back to normal operation mode

OPERATION

8) Open The Door with The EM CARD

---- 2 beeps, the door is open

9) Open The Door with The User PIN

8321

---- 2 beeps, the door is open

10) Open The Door with The EM CARD + User PIN

6123

---- 2 beeps, the door is open

11) Open The Door with The EM CARD + Common User Code

8625

---- 2 beeps, the door is open

REMARK:
In the next Section, “KEY IN AND STORE THE DESIRED VALUES” describes all the features and functions of the system
in detail. Users can follow them to tailor the desired values for their access control systems. Suggest the general users
also spend some time on them to get acquaint with this powerful system for future expansion.

READ CARD
