CTC1000
V. 01 – 12/06/2013 35 ©Velleman nv
the panel will light while this error message can be viewed on
LCD under Fault Display. No alarm event will be reported.
interference  When the system is programmed with Interference detection ON
and when there is an interference detected for 30 seconds, the
yellow LED will light up. The error message can be viewed on
LCD under Fault Display in the user menu.
14.3 Error messages
The error message is displayed in short form as below:
Message displayed
Meaning
AC failure AC Power Fail
GSM Signal GSM out of signal
Interference interference detected
Panel L.B. low battery on the control panel
Panel Tamper sabotage on the control panel
(Sensor w/ Zone Name) + L.B. low battery on the sensor
(Sensor w/ Zone Name) + out sensor out-of-order
(Sensor w/ Zone Name) + Tamper sabotage on a sensor
Sim Card? SIM card missing
Example: the message DC Z 01 L.B. means Zone 1 Door Contact is low battery.
Note
While you arm the system, if any of door contact or PIR is triggered, arming is also prohibited and the sensor
triggered will be displayed as error message.
Message displayed
Meaning
(DC w/ Zone Name) + open Door Contact triggered
(IR w/ Zone Name) + Active PIR triggered
15. Remote Commanding
The unit can be controlled by remote control commands sent via sms messages.
15.1 Remote commanding from a regular phone line
1. Dial the GSM phone number of your control panel and hang up on the first ring.
2. Dial the control panel again after 8 to 20seconds.
You will hear 2 beeps from the control panel via phone set.
3. Enter the user pin code (user 1 ~ user 4).
The first digit of pin code should be entered within 3 seconds.
A valid pin code should be entered with 20 sec. otherwise the Panel will hang up automatically.
4. If the pin code is correct, you will hear 2 beeps from the control panel via phone set.
5. Enter the 2-digit DTMF Control Command.
If the command is correct, you will hear 2 beeps; if not, you will hear 1 beep.
DTMF Remote Control Command Table
Control Command
Action
00 On Hook
01 Listen-in
10 Disarm
11 Arm
20 UR#1 deactivate
21 UR#1 activate
30 UR#2 deactivate
