APPENDIX 5 SPECIFICATIONS
47
For Model 4
Hardware
Video Input One LAN port (Up to 12 Channels with a hub)
Video Output HDMI
Video Output Resolution 1920 x 1080
Audio Output YES
HDD Storage** Up to two 3TB HDDs
USB Ports
Two on the front panel:
one for video backup to USB flash drive, and
another for NVR control via a USB mouse
IR Remote Control YES
LAN port 1000Mbps
Ethernet
Internet port 10Mbps / 100Mbps
Software
Video Compression Format H.264
Local / Remote Display Mode 6 / 12CH
Local / Remote Playback Mode 6CH
Recording Mode Manual / Event / Alarm / Schedule
12CH Mode
Up to 360 IPS @ 720 x 480, 32 Mbps
Up to 120 IPS @ 1280 x 720, 32 Mbps
* Recording @ 1280 x 1024 or higher is only allowed for CH1 Recording
Throughput****
6CH Mode
Up to 180 IPS @ 720 x 480, 32 Mbps
Up to 180 IPS @ 1280 x 720, 32 Mbps
Up to 90 IPS @ 1920 x 1080, 32 Mbps
Pre-alarm Recording YES
Quick Search Time / Motion / Alarm
Security Multiple user access levels with password
Remote Access
(1) Internet Explorer on Windows operating system
(2) EagleEyes on iPhone, iPad & Android mobile devices
Event Notification Push Message / Push Video
General
Power Source (±10%) DC 12V / 3A
Operating Temperature 10℃ ~ 40℃ (50℉~104℉)
Dimensions (mm)** 375(W) × 68(H) × 264.8(D)
Minimum PC Browsing Requirements
Pentium 4 CPU 1.3 GHz or higher, or equivalent AMD ‧
256 MB RAM ‧
AGP graphics card, Direct Draw, 32MB RAM ‧
Windows ‧ 7, Vista & XP, DirectX 9.0 or later
Intern ‧ et Explorer 7.x or later
Peripherals
(1) EoC converter;
(2) High Resolution Display Extender;
(3) Video Server
* Specifications are subject to change without notice.
** HDDs are optional.
*** Dimensional tolerance: ±5mm.
**** Image quality: HIGH.
