CONNECTION
6
2.3 Manual Connection Setup
To manually assign a channel to connect to the IP camera, select a corresponding “PROTOCOL” from the drop
down list first, click “URI” to enter the address of the camera, and enter its port number. There are four protocol
types available in the drop down list as follows: “AVTECH”, “ONVIF”, “RTSP OVER HTTP”, and “RTSP OVER
UDP”. If you are using AVTECH IP cameras, please select “AVTECH”; otherwise, choose the protocols your
cameras support.
ADVANCED CONFIG
CONNECTION CHANNEL PROTOCOL URI PORT PATH CONFIG
CAMERA CH1 AVTECH ://ip_office.ddns.eagleeyes.tw :80 / SETUP
DETECTION CH2 ONVIF ://10.1.1.14 :88 / SETUP
ALERT CH3 RTSP OVER HTTP ://10.1.1.30 :88 / SETUP
NETWORK CH4 RTSP OVER UDP ://10.1.1.12 :88 / SETUP
DISPLAY CH5 AVTECH ://10.1.1.16 :88 / SETUP
RECORD CH6 AVTECH ://10.1.1.13 :88 / SETUP
NOTIFY
EXIT
