18
420E/420E IT Specifications
Loader Bucket Dimensions and Performance
IT Loader with Quick Coupler
General Purpose General Purpose General Purpose
(0.96 m³/1.25 yd³) (1.00 m³/1.31 yd³) (1.15 m³/1.50 yd³)
Capacity (SAE rated) 0.96 m� 1.25 yd� 1.00 m� 1.31 yd� 1.15 m� 1.50 yd�
Overall bucket width 2262 mm 7 ft 5 in 2406 mm 7 ft 11 in 2406 mm 7 ft 11 in
Lift capacity at maximum height 3164 kg 6,975 lb 3162 kg 6,971 lb 3023 kg 6,664 lb
Breakout force 47.1 kN 10,593 lb 47.5 kN 10,672 lb 45.5 kN 10,235 lb
(7) Maximum hinge pin height 3329 mm 10 ft 11 in 3329 mm 10 ft 11 in 3316 mm 10 ft 11 in
(8) Dump angle at full height 45° 45° 45°
Dump height at maximum angle 2507 mm 8 ft 2 in 2539 mm 8 ft 4 in 2493 mm 8 ft 2 in
(9) Dump reach at maximum angle 831 mm 2 ft 9 in 799 mm 2 ft 7 in 801 mm 2 ft 8 in
(10) Maximum bucket rollback at ground level 40° 40° 40°
(11) Digging depth 147 mm 6 in 147 mm 6 in 153 mm 6 in
Maximum grading angle 108° 110° 108°
Width of dozer cutting edge N/A N/A N/A N/A N/A N/A
(12) Grill to bucket cutting edge, carry position 1607 mm 5 ft 3 in 1575 mm 5 ft 2 in 1593 mm 5 ft 3 in
(13) Maximum operating height 4260 mm 14 ft 0 in 4256 mm 14 ft 0 in 4303 mm 14 ft 1 in
J aw opening maximum N/A N/A N/A N/A N/A N/A
Bucket jaw clamping force N/A N/A N/A N/A N/A N/A
Weight (does not include teeth or forks) 434 kg 957 lb 444 kg 978 lb 481.01 kg 1,060 lb
IT Loader with Quick Coupler
Multi Purpose Multi Purpose
(0.96 m³/1.25 yd³) (1.03 m³/1.35 yd³)
Capacity (SAE rated) 0.96 m� 1.26 yd� 1.03 m� 1.35 yd�
Overall bucket width 2279 mm 7 ft 6 in 2425 mm 7 ft 11 in
Lift capacity at maximum height 2800 kg 6,174 lb 2771 kg 6,110 lb
Breakout force 44.5 kN 10,020 lb 44.4 kN 9,983 lb
(7) Maximum hinge pin height 3316 mm 10 ft 11 in 4306 mm 14 ft 2 in
(8) Dump angle at full height 45° 45°
Dump height at maximum angle 2559 mm 8 ft 5 in 2559 mm 8 ft 5 in
(9) Dump reach at maximum angle 748 mm 2 ft 5 in 748 mm 2 ft 5 in
(10) Maximum bucket rollback at ground level 40° 40°
(11) Digging depth 144 mm 6 in 144 mm 6 in
Maximum grading angle 111° 111°
Width of dozer cutting edge 2262 mm 7 ft 5 in 2406 mm 7 ft 11 in
(12) Grill to bucket cutting edge, carry position 1526 mm 5 ft 0 in 1526 mm 5 ft 0 in
(13) Maximum operating height 4306 mm 14 ft 2 in 4306 mm 14 ft 2 in
Jaw opening maximum 790 mm 2 ft 7 in 790 mm 2 ft 7 in
Bucket jaw clamping force 55 700 N 12,521 lb 55 700 N 12,521 lb
Weight (does not include teeth or forks) 724.09 kg 1,596 lb 752.93 kg 1,660 lb
Dimensions and performance specifications shown are for machines equipped with 12.5/80-18 SGL front tires, 19.5L-24 IT525 rear tires, ROPS canopy, standard stick with
610 mm (24 inch) standard duty bucket, and 0.96 m³ (1.25 yd³) loader bucket and standard equipment unless otherwise specified.
